PE/PP WPC Profile Extrusion Line
Single screw extruding prduction line is mainly for producing PE/PP/WPC profiles.
Machine list:
1. Single screw extruder
2. Profile mould
3. Vacuuming and calibrating
4. Cooling water tank
5. Profile haul-off machine
6. Profile cutting machine
7. Profile Stacking machine
Low power consumption, high output
|
Model |
YF-180 |
YF-240 |
YF-400 |
YF-610 |
YF-810 |
|
Length of the calibration table (mm) |
4000 |
6000 |
8000 |
9000 |
11000 |
|
Max profile width (mm) |
180 |
240 |
400 |
610 |
810 |
|
Drawing speed (m/min) |
0-8 |
0-6 |
0-5 |
0-5 |
0-5 |
|
Power of extruder |
SJZ51/105
18.5KW
(22kw) |
SJZ55/110
22kw |
SJZ65/132
37kw |
SJZ80/156
55kw
(75KW) |
SJZ92/188
110kw
|
|
Length of the calibration table (mm) |
4000 |
5000 |
6000 |
8000 |
Our company is a company that engaged in providing all kind of plastic recycling machinery. We are especially specialized in manufacturing and exporting recycling machines such as:
Single-Shaft Shredder, Double-shaft Shreder, Four-shaft Shredder, Plastic Crusher, PET Flakes Washing and Recycling Machine, PE/PP Film/Woven Bags Washing and Recycling Line, PE/PP/PET/PA/PS/PC/ABS, etc. Pelletizing Line, Film/Woven Bags Squeezer; And the high-speed mixer and plastic pipe production line are also in our range of specialization, we are providing other relative auxiliary machines at the same time.
Innovation and creation is our constant goal, and our company has already had a complete machinery manufacturing system after years of technological breakthroughs.
We provide customers with high-quality equipments. Our headquarters is in Zhangjiagang city along the Yangtze River. We have administrative systems to strengthen our company. We also have a complete and scientific quality management system to ensure our product quality. Our goal is providing customers high-quality machines and creating win-win situation.
We welcome friends worldwide to our factory for visiting, guiding and doing business negotiations. We are looking forward to establishing long-term business relationships with you in the near future.
