MOLD STEEL:
1. Cavity steel: Cavities use 2316 stainless steel, tempered with HRC 44+/-2
2. Core steel: Cavities use 2316 stainless steel, tempered with HRC 48+/-2
3. Neck screw steel: Neck screw use 2316 with tempered HRC48+/-2
4. Plate: P20, Made In China
5. Other spare parts: Nozzle: H13; Tip: Copper with HRC40; Cylinder: P20 Made In China; PIN: SKH61 Made In Japan, HRC60; Ring: DuBang in USA
MOLD DESIGN
1. Design: All the moving area was inserted with durable parts which is interchangeable
2. Drawing: 2D mould assembling drawing and part drawing available with shipment.
Tooling Spec.
1. Cooling system Optimal cooling design and all the cooling syestem are Nickel plated
2. Ejection syestem Automatic ejection system, Knock out by machine and ejector return by machine
3. Polishing Precision polishing until the core and cavity like the mirro
