Plastic Corrugated Pipe Production Line
| Price: |
US $ 30000-100000/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T |
Qingdao Jinfuxin Plastic Machinery
PVC pipe extrusion line
PVC pipe production line
Pipe extruder machine
Pipe extrusion machine.
PVC Plastic Pipe Extruder Making Machine
CE&ISO quality certification
Introduction of Corrugated plastic pipe production line
STRUCTURAL FEATURE of Corrugated plastic pipe production line
1. Equipped with two high-efficient single screw extruders and notching machine barrel to ensure effective extrusion of different materials for two walls.
2. Highly effective cooling system can ensure high speed production in continuity.
3. Nitrogen treated moulds and adjustable wall thickness device can ensure production with different materials and HG degree.
4. Corrugated moulds are made of precisely casted special alloys which can provide high precision and pressure resistance as well as good heat elimination effects.
5. Advanced pipe end expansion functions reduce much investment cost and enhance productive force.
6. The line adopts advanced Siemens PLC control system and large liquid crystal screen handling system, which realizes high automation, reliable operation and easy handling.
|
Type |
Pipe Diameter
(mm) |
PVC Output
(kg/h) |
PE/PP Output
(kg/h) |
MAX Speed
(m/min) |
Total Power
(KW) |
|
WR-160 |
90-160 |
150-250 |
200-300 |
6.0 |
9.7 |
|
WR-250 |
110-250 |
250-350 |
250-350 |
5.0 |
8.6 |
|
WR-500 |
200-400 |
650-750 |
250-500 |
3.0 |
16.9 |
|
WR-800 |
500-800 |
--- |
1000-1100 |
3.0 |
16.9 |
|
WR-1200 |
800-1200 |
--- |
1000-1200 |
1.0 |
30.0 |
| Prod Model: |
JFX-65/132 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Max. Output: |
680kg/H |
| Specification: |
200-500mm |
| Total Power: |
280kw |
| Certification: |
ISO9001:2008 |
| Automation: |
Automatic |
| Product Type: |
PVC Pipe |
| Computerized: |
Non-Computerized |
Qingdao Jinfuxin Plastic Machinery Co., Ltd is a state designated enterprise producing plastic machinery and high-tech enterprise in Qingdao. Mainly engaged in research & development, manufacturing, sales, and after-sale service of new plastic machinery. Products consist of PVC Crust Foam Board Production Line, Plastic Grass Mat Machine, PET/PP Strap Production Line, PA/PP/PE/PET/PBT Filament Extruding Machine, etc. And all kinds of plastic pipe, profiles, board, bar extrusion line and auxiliary equipment. Our machines are popular with the customers, which are sold all over the country and exported to Southeast Asia, Russia, Ukraine, Iran and other countries.
Since our company has establishd, it always takes the domestic and international market as the guide, the technology as leader, the quality as the life, strengthens joint units with domestic colleges and universities of science and technology and brings in and absorbs foreign advanced technology, in a timely manner to develop new plastic industry products according to the market demand, provides customers with a complete innovative set of production line, takes customer satisfaction as the ultimate goal, to strive for the best plastic machinery in China.
And expand the Qingdao Jin Xinquan Plastic Products Co., Ltd., production of plastic corrugated pipe products are mainly used for electrical threading pipe, auto threading pipe, casing, machine tool products, food packaging machinery, electric locomotives, engineering installation, lamps and lanterns, automation instruments and meters, etc
Jinfuxin company aim "morality for the surplus, credit management, service oriented, joint development, shaping the future".
