Plastic multi-cross pipe fitting/coupling mold/mould
This part is new concept project designed by our R&D team according to customer's hand-sketch picture.
Name |
Plastic multi-cross pipe fitting/coupling |
Material |
PVC |
Size |
190*190*100mm |
Working Condition |
-15° -55° |
Applications |
Connect pipes together, water supply, drainage, gutter |
Guarantee |
50years of service life |
Mold Status |
1)1x1 Cavity
2)Cold runner system
3)Imported S136H material |
Technical Difficulty |
Overmolding process with too many brass inserts
Working efficiency of injection production
Machining tolerance of brass inserts for strict requirement on overmolding. |
Why Choose Us |
1)During all period of many years of experience accumulation, we have successfully summarized and developed efficient methods of manufacturing pipe fitting/coupling with top quality and punctual leadtime of shipment .
2)Fully automatically ejecting system which increases working efficiency.
3)Imported S136H guarantees stability of mass production and life.
4)Mold surface plated with hard chrome to increase gloss to optimize water flow.
5) Standard manufacturing procedure with ISO 9001: 2008 certificated.
6) We own the principle that quality first, customer first, and are responsible for all defects and loss resulted from goods. |
