Plastic PE Drainage Pipe Making Machine
| Price: |
US $ 40000-100000/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T |
Qingdao Jinfuxin Plastic Machinery
PE pipe extrusion line
PE pipe production line
Pipe extruder machine
Pipe extrusion machine.
PE Plastic Pipe Extruder Making Machine
CE&ISO quality certification
Process Flow PE Drainage Pipe Making Machine
Raw material + additive mixing vacuum feeding machine hopper dryer single screw extruder color code extruder mould and calibrator vacuum forming machine cooling tank haul-off machine cutting machine discharging rack
Description of PE drainage pipe making machine
This PE drainage pipe making machine can be used in PE Large Diameter Gas and Water Pipe which have excellent stiffness and flexibility, heat resistance, aging resistance, high mechanical strength, resistance of environmental stress cracks, resistance to creep deformation, heat-linkage, and so on. So, this pipe production line is a preferred gas and water pipe for ductwork system between city and its suburb.
Large diameter HDPE pipes start to play very important role in the city water and gas supply systems.
Characteristics
Capacity: Single screw extruder, suitable to process PE resin with high capacity, max 1000kg/h
Diameter: From 16 to 800mm
Adopts reasonable design, absorbing safe producing technology, acquiring CE&ISO certificate
|
Main Eetruder |
45/33 |
75/33 |
60/33 |
75/33 |
990/33 |
90/33 |
120/33 |
120/33 |
150/33 |
150/33 |
150/33 |
|
Pipe Diameter |
16-63 |
16-63 |
32-125 |
75-250 |
110-450 |
160-500 |
160-500 |
250-630 |
315-800 |
450-1000 |
630-1200 |
|
Die Head |
Single Outlet |
Double Outlet |
Single Outlet |
|
Down-stream Equipment |
LG63 |
SLG63 |
LG125 |
LG250 |
LG450 |
LG500 |
LG500 |
LG630 |
LG800 |
LG1000 |
LG1200 |
|
Total Power |
70 |
125 |
150 |
230 |
380 |
380 |
550 |
550 |
800 |
800 |
1000 |
| Prod Model: |
JFX-65 90 120 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Max. Output: |
100kg/H |
| Specification: |
16-800mm |
| Certification: |
ISO9001:2008 |
| Automation: |
Automatic |
| Product Type: |
PE Pipe |
| Computerized: |
Non-Computerized |
Qingdao Jinfuxin Plastic Machinery Co., Ltd is a state designated enterprise producing plastic machinery and high-tech enterprise in Qingdao. Mainly engaged in research & development, manufacturing, sales, and after-sale service of new plastic machinery. Products consist of PVC Crust Foam Board Production Line, Plastic Grass Mat Machine, PET/PP Strap Production Line, PA/PP/PE/PET/PBT Filament Extruding Machine, etc. And all kinds of plastic pipe, profiles, board, bar extrusion line and auxiliary equipment. Our machines are popular with the customers, which are sold all over the country and exported to Southeast Asia, Russia, Ukraine, Iran and other countries.
Since our company has establishd, it always takes the domestic and international market as the guide, the technology as leader, the quality as the life, strengthens joint units with domestic colleges and universities of science and technology and brings in and absorbs foreign advanced technology, in a timely manner to develop new plastic industry products according to the market demand, provides customers with a complete innovative set of production line, takes customer satisfaction as the ultimate goal, to strive for the best plastic machinery in China.
And expand the Qingdao Jin Xinquan Plastic Products Co., Ltd., production of plastic corrugated pipe products are mainly used for electrical threading pipe, auto threading pipe, casing, machine tool products, food packaging machinery, electric locomotives, engineering installation, lamps and lanterns, automation instruments and meters, etc
Jinfuxin company aim "morality for the surplus, credit management, service oriented, joint development, shaping the future".
