Low power ultrasonic water meter is designed according to Europe alliance EN1434 standard and ultrasonic time-difference principle. It can instead of other water meter and Install in any angle. Ultrasonic time-difference principle Measuring water or other liquid
Accuracy: 1%, 2%
Repeatability: 0.5%
Measuring period: 3S, 1~31S(selection)
Battery can work 6-10years, or two line power
Lowest measuring velocity of liquid 0.01m/s
No pressure lost and moving parts, no nursing for 10 years
Pipe length designing according to the normal water meter
IP68, can working under water lower than 2 meters
Foundry in mould, no reveal
DN15-1000mm
Ceramic sensor apply to -40~160
Over look type, normal type, separate type
| Sensor | S1 | M1 | L1 | S1H | M1H |
| Pipe size(DN) | 15-100 | 50-700 | 300-6000 | 15-100 | 50-700 |
| Material | ABS | Special material for H -temp |
| Frequency | 1MHz |
| Installation | V(N/ W) | V/ Z | Z | V/(N W) | V/ Z |
| calibration | Calibrated together with flowmeter |
| magnetism | Magnetic | No magnetic |
| Temperature | 32ºF~158ºF(0-70) | 32ºF~320ºF(0-160) |
| Protection class | IP65 |
| Dimension(mm) | 45*30*30 | 60*45*45 | 80*70*55 | 90*85*24 | 90*82*29 |
| Weight(g) | 75 | 250 | 650 | 94 | 150 |
| Liquid types | Water. Sea water waste water. chemicalliquids. oil, crude oil. alcohol. beer. etc |
| Suspension concentration | ≤10000 ppm with little air bubble |
| Pipe | Carbon steel stainless steel cast iron Brass PVC Aluminum etc. |
| Pipe liner | Rubber Slurry PP PS bakelite,PTFE |
| Signal cable | Standard:5M* 2 optinal:10M* 2 or 15M *2 |
Payment term
1.Loading Port: Shanghai China
2. Samples Leading Time: 3-7 working days
3. Delivery Time: Within 7-15 days after payment
4.Payment: T/T, Western Union, Paypal
After-sales service After
1. Warranty: The warranty period is 12 months starting from the shipping date
2. Customers will enjoy free repair services for failures found within the warranty due to manufacturing quality
3. For on-site services not arising from manufacturing quality, we shall charge a certain ser After-sales service vice fee at our discretion based on actual charges incurred such as travel exp
4. We provide paid repair services for meter damages not arising from manufacturing quality issues or meter damages not within the scope of warranty.
Cixi flowmeter Co., Ltd. Was established in 2008 and since then has been dedicating itself to research and manufacture of various kinds of flowmeter. With sophisticated experience in technology and management, CIXI Flowmeter has made a name for itself as an excellent manufacturer of various kinds of flowmeter. In 2007, we have especially set up Shanghai Cixi Instrument Co. Ltd for handling the deals of Export.
Thanks to outstanding performance of products, CIXI Flowmeters are being applied in more and more fields where there' S liquid to measure. CIXI Flowmeters have found users in many countries besides China, such as Malaysia, India, Thailand, Vietnam, South Africa and so on. Increasing number of users are finding that CIXI Flowmeter are kind of product with super performance and reasonable price.
