Lightweight wall panel concrete machine
1) HQJ model lightweight wall panel machine by Haitian company has got China National Invention Patent. Patent No.: ZL20090025183.7
2) The concrete product produced by HQJ machine can be used As internal walls, external walls, roof of houses with the materials of cement, sand and aggregate.
3). HQJ panel machine is a movable producing panel machine which need simple platform to move during producing.
4) Steel wire of 2mm diameters are put inside the panel in advance before producing
5) ISO 9001&CE certified company
Model HQJ | Slab width (mm) | Slab thickniss (mm) | Dia. Of holes | Forming speed (m/min) | Motor Power (KW) | Vibrator (KW) | Weight (kg) |
80*600 | 595± 2 | 78± 1 | 8xΦ 43 | > =1.6 | 4 | 0.8 | 1010 |
90*600 | 595± 2 | 88± 1 | 7xΦ 58 | > =1.6 | 5.5 | 0.8 | 1010 |
100*600 | 595± 2 | 98± 1 | 7xΦ 62 | > =1.6 | 5.5 | 0.8 | 1035 |
120*600 | 595± 2 | 118± 1 | 5xΦ 82 | > =1.6 | 5.5 | 0.8 | 1650 |
200*600 | 595± 2 | 198± 1 | 3xΦ 145 | > =1.6 | 7.5 | 3 | 1680 |
240*280X2 | 280± 2 | 238± 1 | 2xΦ 165 | > =1.6 | 7.5 | 3 | 1700 |
Dezhou Haitian Electromechanical Technology Co., Ltd. is specialized in manufacturing prestressed concrete making machine. Our products mailnly include concrete floor slabs machine, conrete lightweight wall panels machine, beam making machine, purline making machine, concrete pipe making machine, steel bar tensile machine, and other auxiliary equipment.
