Preform Mold (48CAVITY)

Injection preform mold

48cavity PET preform mold with hot runner system. Pneumatic pin valve, nozzle gate design. It is supply separate temperature controller for each cavity.
The material of mould die core and die cavity are made of Sweden special mould steel.
International standard screw neck, imported nitrogen steel with high hardness is of long usage.
Advanced hot runner design and even heating temperature make sure the high quality of plastic products.
Valve gated type without tail reduces labor force.
At least 3 million guarantee.
High quality and very good price!
Great machinery and mold, Molding your dream!

Mold construction character:

I. Off-center Adjustment System
Off-center adjustment system can make the error of preform's wall thickness less than 0.05mm. This system does not affect the lifetime of mold;

II. Self-lock System
International advanced bi-awls fixed orientation self-locked structure has been adopted.

III. Cooling System
All the water Channels in the mold's each inner part, which make the cycle time short enough. And all the cooling channels have been specially treated to prevent them from jam;

IV. Heating System
Double Heating System can ensure that the impact of heating is good and quality control is credible. The Heating Band unit makes nozzles be with invariable temperature. The Heater Unit is used to heat the hot runner plate with long using life and powerful heating capacity.

V. Hot Runner System
The perform mold adopt Pin-valve type Hot Runner System, such hot runner system can reduce mold's each part's wear & tear and maintenance cost, and also save 10%~15% electric energy;
