Home Mould Products PVC Foam Board Machine

PVC Foam Board Machine

PVC Foam Board Machine
Price: US $ 48000-95000/Set
Trade Terms: FOB,CFR,CIF
Min Order: 1/Set
Pay Type: L/C,T/T,D/P,Paypal,Money Gram


Most professional manufacturer in pvc foam board machine in China (PLC Control)
PRODUCT INTRODUCTION

PVC WPC Foam Board Machine is our latest updated products. It's continuously improved on the basis of requirements and feedbacks from our customers and combined with foreign advanced technology. It shows superior performance, high reliability and practicality with its compact structure, advanced configuration and outstanding output in the production of 3-20mm thick, high-qualified PVC WPC foam board.

Our extrusion line adopts Celuka foam technology, which can produce a kind of PVC/WPC foam boards with superior quality. These processes result in a "skinning" or outer layer of foam board and it achieves excellent surface hardness, rigidity and toughness and more scratch-resistance. This kind of furniture foam board has smooth and shining surface with characteristics of lightweight, scratch-resistant, durable, water and weather resistant, anti-corrosion, impervious to salts, insects and many chemicals including some acids. PVC WPC foam board can be nearly 100% recycled and reused. Besides, PVC WPC office foam board can be worked like wood with the tools for wood. It's suitable for sawing, cutting, nailing, screwing, planning and sticking. It's the perfect substitute for wood plates and steel plate.


Main Technical Parameters


Model

Unit

SJSZ80/156

SJSZ92/188

SJSZ80/156, SJ65/132



Product width

mm

1220

1600

1600-2050



Product thickness

mm

3-20

5-30

3-20



Max. extrusion capacity

Kg/h

350

500

600



Power of extruder

KW

75

110

120



1.SJSZ 80/156 Conical twin Screw Extruder
ABB Frequency Converter, SIEMENS Contactor, OMRON  Japan, Motor Power:75KW



2.Calibration unit
Calibration Plate:1500mm×500mm  4couples
3. Cooling Tank and Bracket
Length:6000mm
Trimming Knife:3 sets
4. Haul-off Unit
8 Couples
Cylinder Clamping and Loosening
5. Cutting unit
6. Stacker
 7. Mould (T-Die )


lntroduction of  PVC foamed board .
 This is a completely waterproof material, because it is plastic, it is widely used in the place of the outside balcony, Plank Road, a swimming pool, lake, beach, ship deck and so on.
Secondly, this is a completely anti-termite, anti-moth-eaten material, because it does not contain fibrin.
Third, this is a material with a good performance of flame retardant. We have done experiments. This excellent fire retardant property of foam boards foam is much better then wood and wood-plastic materials.
Fourth, it is one that does not decay, is radiation-free and non-toxic and in line with national testing standards. It is maintenance-free, and the maintenance of pollution can be avoided.
Fifth, the bending resistance of this material and a surface hardness are higher than that of wood, wood materials. The grip nails is stronger than the wood-plastic which is flat with wood.
Sixth, price levels of this material in the current market has the promotion conditions, it is definitely cheap and fine

CHARACTERISTICS OF PVC WPC FOAM BOARD


PVC foam board has such characteristics as sound separation, sound absorption, heat separation.
The material is incombustible, it is safe for use.
All series of products have property of moisture proof, mildew proof, water resistance; its vibration resistant effect is good.
All series of products have property of weathering proof, its luster may remain forever,and it is not easy to be ageing.
This product is light, storage & transport, construction are rather convenient.
This product can be worked with normal tools for wooden material.
Drilling, sawing, nail, bonding can be conducted like wooden material.
It is suitable for thermal shaping, thermal bending and fold processing.
It can be welded; it can also be bonded with other pvc material.
The surface of this product is smooth, it can be printed. (Clean the surface before printing).


TECHNIQUE GUARANTEE

Our extrusion line adopts Celuka foam technology, which can produce a kind of PVC WPC foam boards with superior quality. These processes result in a "skinning" or outer layer of foam board and harder or morescratch resistant. This kind of PVC WPC foam board can not only have much smoother surface but also have more skin hardness compared with other PVC WPC boards.

EQUIPMENT STRUCTURES


ComponentSpecification
1 Generation Extruder75kw (speed adjusted by ABB inverter)
80/156 conical double screw
OMRON Temperature controller
Output is about 400kg/h.
Automatic feeder
2 Mould(3mm-20mm) x1220mmx2400mm
3Calibration UnitCalibration plate: 1500mm× 500mm 4couples
4Cooling roller systemLength: 6000mm
Trimming knife: 3 sets
5Haul off machine8 pairs rubber rollers (controlled by inverter) and electric trimming machine
6End Cuttercontrolled by inverter
7Stacker



TOP ELECTRICAL CONFIGURATION

1. Main motor frequency controller: SIMENS or ABB

2. Temperature controller: OMRON or RKC

3. AC controller: SCHNEIDER or SIMENS

4. Thermal overload relay: SCHNEIDER

5. Switch: SCHNEIDER

6. Electric control system: PLC

PRODUCTION PROCESSING

Material Mixing: PVC + additives or PVC + wood powder + additives

Extrusion Processing: mixed material going through the extruder, Mould, calibration unit, cooling carrying roller and trimming cutter, and delivery device.

Final Products: PVC or WPC foam board

SPECIFICATION OF FINISHED BOARD

Specifications of PVC WPC Foam Board
Length1830mm/2440mm
Thickness3mm~20mm
Width915mm/1220mm
Density0.37g/cm 3 -0.85g/cm 3
surfaceSmooth or wood grain pattern(timber ridge) finish
colorWhite, wood or all feasible colors as requested


Company Information & Professional Service

WUXI BOYU Plastic Machinery Co., Ltd., located in wuxi, China, is a professional manufacturer of PVC Celuka Foam Board production line. With more than 10 years' research and development, boyu now are proud of these production lines: PVC/WPC (Wood Plastic Composit) crust foam board extrusion line, PVC crust foam board extrusion line, PVC wood plastic foam board extrusion line, PVC building board extrusion line and PVC free foam board extrusion line.

Pre-sale service:
To provide information and market research,to provide consultation,to provide many kinds of conveniences and market service,etc. Products: PVC Foam Board Machine...
The main purpose of pre-sales service is to help customers make the project planning and system requirements analysis. Make our products maximum to meet clients' requirements. Also play the greatest overall economic benefits of customers' investment.
After-sale service:
To install products and test products freely for customers.
To provide the formulas and technologies of relevant products and the information of chemical materials manufactories.
To direct technology aspect of relevant use according to customers' requirements
To provide technical training for clients' employees.
To be responsible for maintenance service, door-to-door service under the necessary circumstance.
Technology support:
To provide installation and test for the machine.
To provide formulas and technology of relevant products.
To provide information of chemical material manufactories.
To provide technical training for clients' employees.
Prod Model: BYSJ
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Type: Sheet Extruder
Plastic Processed: PVC
Feeding Mode: One Feed
Assembly Structure: Separate Type Extruder
Screw: Twin-Screw
Engagement System: Intermeshing
Screw Channel Structure: Deep Screw
Exhaust: Exhaust
Automation: Automatic
Computerized: Computerized
Product Type: Extrusion Molding Machine
Wuxi Boyu Plastic Machinery Co., Ltd. is one of the most professional WPC PVC foam board production line manufacturer in China. The main production is PVC WPC(wood plastic) foam board extrusion machinery. BoYu pay attention to technological innovation, actively introduce advanced foreign technology, and constantly develop new products.

As one of the earliest domestic manufactories to develop WPC machine/PVC foamed board extrusion line, our company is the professional manufacturer in wood-plastic machinery in China. We have large number of senior experts and technician in WPC/PVC extrusion line, molds, process formula and product production. Accumulated rich experience in the area of WPC/PVC extrusion line, we can provide all-round service and turn-key project.

Our company has passed the CE/SGS/BV quality system certification, and carried out the production in strict accordance with the quality system certification to ensure the quality of products.

Our main products:

1, WPC/PVC foam board production line;

2, WPC/PVC hollow Door board production line;

3, PVC imitation marble wall panel sheet production line;

4, WPC(PE/PP/PVC+wood) profile production line;

5, PVC wall panel production line;

6, Plastic auxiliary equipment.

7, PVC Sheet production line

Our machines are in good quality and various kinds. What you want, we can!
