Gold PVD coating machine is an ion coating machine of efficiency, harmless and pollution-free. It has the features of fast deposition rate, great ionization rate, big ion energy, easy operation, low cost, large productive capacity, etc.
Characteristic: The principle of the electric arc is intergrating cold cathode arc discharge self-sustained light unite pulse technique and magnetron sputtering technology, thinning the particles to improve the properties of the film. It can coat on the surface of the metal as well as nonmetal.
Applied industry: It can be used to coat metal film, titanium nitride, titanium carbide, and zirconium nitride, chromium nitride and titanium, nickel, chromium, copper, and other compounds film, multi-layer super-hard film, nitrogen-doped titanium film and the alloy film, and in a very short time to complete all the machining process, it is a highly efficient multi-functional coating equipment
This machine is extensively used in the fields of ultra-hard coating about the tools and mould, decorative coating about car wheels, ceramics, golf, watches making, hotel product, sanitary ware, luminaires, optical frame, hardware ect.
All the vacuum coating machines are the environmental protection products, and sooner or later will rplace the traditional galvanization industries.
Mode
Dimension |
JTL-900 |
JTL-1100 |
JTL-1300 |
JTL-1600 |
|
Φ900*1000mm |
Φ1100*1000mm |
Φ1300*1200 mm |
Φ1600*1300 mm |
Coating mode and main confirguration |
3 electric-arc+2 pairs of plane rectangular cathode |
6 electric-arc+2 pairs of cylindrical cathode+a pairs of plane rectangular cathode |
6 electric-arc+4 pairs of cylindrical cathode+a pairs of plane rectangular cathode |
8 electric-arc+8 pairs of cylindrical cathode+a pairs of plane rectangular cathode |
|
Application |
metal decorative coating |
|
Film Types |
Metal films,Dielectric films,Compound films,Reaction films,Muti-layer function films |
|
Power source |
Electric arc power supply,DC magnetron power supply,MF magnetron power supply.Pulse bias voltage power supply.ion source power supply. |
|
Process gas control |
Quality flowmeter + electromagnetism ceramic valve |
|
Vacuum chamber structure |
Vertical single(side) door, pump system postposition, double water-cooling |
|
Vacuum system |
Molecule pump(diffusion pump)+Roots pump +Mechanical pump (8.0*10 -4 Pa) |
|
Pumping speed |
Pumping time less than 15 minutes ,from atmospheric pressure to 310 -3 Pa |
|
Workpiece baking temperature |
Normal temperature to 350 centi-degree PID control, radiation heating. |
|
Workpiece motion mode |
Public rotation Frequency control: 0-20 rotation per minute |
|
Measure mode |
Number display composite vacuum gauge: from atmosphere to 1.0*10 -5 Pa |
|
Control mode |
Full automation control system PC+PLC/PC+HMI |
|
Remark |
We can design the dimension of the equipment according to customers special technique requirement. |
DongGuan HuiCheng Vacuum Technology Co., Ltd is a high-tech enterprise specialized in the R&D, Production and Marketing of various kinds of the vacuum equipments. Our company aggregates many excellent technicians in the vacuum industry, including engineers with the senior and middle technique titles. We also invite the senior experts and experienced technicians to be responsible for the development and design of the new products, insure the high technology and quality of the vacuum equipment. Our products are popular with both the domestic and overseas clients, and have a high reputation in the vacuum industry.
Our company is dedicated to the R&D of the series of the vacuum coating machine. We have been designed various coating technics projects according to different requirements successfully, especially in the fields of mobile(computer) shell, electronical appliance, metal, auto parts and high-tech industries, etc. Particularly we designed the special wheels coating machine for the VIP enterprise in Zhejiang Province in 2007, bringing great benifits for the client, making prominent contribution to the environment protection and generating extremely positive social effectiveness. It is high appreciated by the government and craft brother. Therefor this project is listed to the item of the Nation Star Project. Our main products also include slide valve vacuum pump, Roots vacuum pump, water ring vacuum pump, rotary-vane vacuum pump, various vacuum units and different vacuum heating energy equipments, etc.
