Induction Heater for Pipeline heating, pre welding, post welding
Pre Heating Machine-Induction heating
Applications:
1. Pre-heating: For coating, bending, fitting unfitting, welding.
2. Post-welding heat treatment: Tank, boiler or other metal jobs
3. Heating: Mold heating, shipboard, zinc bath, large& irregular metal parts
4. Pipeline heating: Pipeline oil, pipeline gas, pipeline water, pipeline petrochemical and other pipeline material
Process:
Induction Heating
Input Power:
380V, 3 phase, 50/60Hz
Output Power
PWHT-20: 2KW ~ 20KW
PWHT-40: 2KW ~ 40KW
PWHT-50: 2KW ~ 50KW
PWHT-60: 2KW ~ 60KW
PWHT-80: 4KW ~ 80KW
PWHT-100: 4KW ~ 100KW
PWHT-120: 4KW ~ 120KW
Output Frequency:
2kHz ~ 36kHz
Heating Temp Range:
0º C ~ 1100º C
Heating Speed:
5 º C~ 400 º C per minute
Cooling: Air Cooling
Thermocouple: K Type
Features:
1. Digital Display and Adjust for parameters, like output power and temperature setting up.
2. High Efficiency: Electric Power is converted directly to heat power with low power loss.
3. Failure Alert: Once operation occurs, a sounding alarm is activated and error box shown on PLC touch screen.
4. Integrated Module Design: System is more stable and low cost for maintenance.
5. Digital Recorder with optional printer is able to record the temperature data and create chart trends of the heating progress.
6. Accurate Measurement for temperature: Multi-points to detecting temperature; 6 channels for temperature control with ± 3° C tolerance; Evenly heating.
7. Air Cool system allows system work at ultra circumstance: -30 º C~ 50º C
8. IGBT Module: We adapt advanced IGBT Technology.
9. Smart control: All operation is micro computed and controlled through PLC touch screen.
10. Easy to install: Quick-release coupling.
11. Easy To Move: Through Lifting Eye or Wheel System.
12. Safe: Automatical Protect for Power Failure.
13. Universal connector: Water-proof; Insulation.
14. IP 25 Class Protection Level
|
Model |
PWHT 40 |
PWHT 50 |
PWHT 60 |
PWHT 80 |
PWHT 10 |
PWHT 120 |
|
Input Power |
3*380VAC or 3*220VAC or 3*440VAC |
|
Output Frequency |
2KHZ ~ 36KHZ |
|
Output Power |
40KW |
50KW |
60KW |
80KW |
100W |
120KW |
|
Input Current |
60A |
75A |
90A |
120A |
150A |
180A |
|
Weight |
130KG |
136 KG |
140 KG |
145 KG |
168 KG |
180 KG |
|
Size |
800*560*1350mm |
|
Packing Size |
900*660*1560mm |
Shanghai electrical Motor Industrial and Trading Company is a professional Chinese supplier for design, manufacture, and export the heavy industrial facility for metallurgy, mining industry. Our developed products are widely used for melting, heating, metal hardening, pipeline heating, brazing, casting, soldering, annealing, forging, bonding, etc. We have four business divisions for various industrial and commercial applications after internal structure reform.
We have professional team of RD and production. They initiate the induction of heating power with environmental protection and highly effective energy conservation, positively and diligently. Now we have series of products, including the Medium, High, Ultra-high frequency induction heating equipment and special systems. These products are widely applied in the metal heating and processing.
Our company was certified to ISO quality system. Advocating quality management conception of producing products with zero defects, the quality is guaranteed. Now our products are popular not only in China but also oversea such as Japan, USA, Russia, England, Germany, America, Canada, Australia, Thailand, India, Korea and South Africa, etc.
Our Products for Industrial Engineering Application:
Heat treatment: Hardening, induction tempering, and induction annealing.
Induction heating prior to deformation: Forging, swaging, upsetting, bending, and piercing.
Induction brazing and induction soldering: Brazing of steel, brass steel, copper and alloy to each other.
Induction for shrink fitting: In any manufacturing process, e. G. Shrink fitting of motor rotors to shafts, shrink fitting of shell casings for compressors.
Induction heating prior to coating: Of dissimilar metals, prior to insulation, and curing, such as paint.
Induction melting: Of all types and amounts of metals and precious metals. We have both basic type and advanced intelligent melting systems.
Induction prewelding and postwelding heating treatment: For large and irregular metal parts. The coil is made of high temperature line of pressure transducer. It is easy to make an adjustment according to different metal parts.
