| Price: | US $ 3000-4500/Piece |
|---|---|
| Trade Terms: | FOB,CIF,EXW |
| Min Order: | 1/Piece |
| Pay Type: | L/C,T/T,Western Union |
Laser power: | 60W |
Laser type: | CO2 tube |
Power supply: | AC220±10% 50HZ/AC110±10% 50HZ |
Working area: | 900*600mm |
Machine dimension | 1970*1600*1220mm |
moving speed: | 0-60000mm/min |
Locating precision: | <0.01mm |
Min shaping character: | Character:2x2mm,Letter:1x1mm |
Operating temperature: | 5-40 °C |
Resolution ratio: | ≤0.01mm |
Control configuration: | DSP |
Data transfer interface: | USB(offline) |
Worktable | 90*60CM |
System environment: | WINDOWS 2000/WINDOWS XP |
Cooling way: | Water cooling and protection system |
Graphic Format Supported | The Files which CorelDraw, Photoshop, AutoCAD can identify (BMP,GIF,JPEG,PCX,TGA,TIFF,PLT,CDR,DMG,DXF,PAT,CDT,CLK, DEX,CSL,CMX,AI,WPG,WMF,EMF,CGM,SVG,SVGZ,PCT,FMV,GEM,CMX) |
Compatible software: | CorelDraw, AutoCAD |
Cutting thickness: | 0-20mm(depends on different materials) |
Color separation: | Separation of cutting up to 256 colors |
Sloping engraving: | Yes,slope can be designed discretionarily |
Cut off the water supply the protection | Yes |
Packing | Wooden case with foam |
Optional parts: | High-grade cooling system/imported focus lens/double-head/ cylinder rotary attachment/irregular rotary attachment |
Weight | 180KG |
| Prod Model: | KTG-9060 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Laser Type: | Laser Engraving Machine |
| Control: | CNC |
| Current: | DC |
| Usage: | Mould |
| Cutting Area: | 1300*900mm/900*600mm |
| Cooling Mode: | Water Cooling |
| Cutting Thickness: | 0-20mm(Depends on Different |
| Graphic Format Supported: | Ai, Plt, Dxf, BMP, Dst, Dwg, La |
| Cutting Speed: | 0-40000mm/Min |
