Equipment List
No. | Name | Quantity |
1 | EPS Cold Press Recycling Machine | 1 set |
2 | Extruding system 1 | 1 set |
3 | Extruding system 2 | 1 set |
4 | Water cooling tank | 1 set |
5 | Air dryer | 1 set |
6 | Cutting machine | 1 set |
7 | Air blower system | 1 set |
8 | Silo | 1 set |
9 | Control cabinet | 1 set |
1. EPS cold press recycling machine
capacity: 100kg/h
density ahieved: 300kg/m3
block measurement: 30*30cm
main motor: 7.5kw
hydraulic pump: 0.55kw
pre-crusher: 1.5kw
pre-crusher heavy duty: 2.2kw
length: 4.1m
width: 0.6m
height: 1.7m
weight: 1200kg
2. Extruding machine
screw diameter: 100m
motor power: 55kw, frequency control
L/D: 20:1
screw & barrel material: 38CrMoALA
screw barrel: 4kw*6 heating zone, adopt ceramic heating method
cooling fan: 0.24kw*6 unit
force feeding motor power: 3kw
mould heating zone: 4kw*2
mould material: 40Cr
vacuum pump: 2.2kw*1 pcs
3. extruder
screw diameter: 100mm
motor power: 20kw
L/D: 10:1
screw & barrel material: 38CrMoAIA
barrel heating zone: 5kw*3 unit
cooling fan: 0.24kw*3 unit
mould heating zone: 4kw*2
mould material: 40Cr
4. water cooling tank
tank length: 4000mm
tank made of SUS304
5. air dryer
motor power: 2.2kw
pipes are made of 304 stainless steel
6. cutting machine
motor: 3kw, frequency control
cutting blade qty.: fixed blade 1 pcs, rotary blade 1 pcs
7. air blower system
the power of the air motor: 7.5kw
the diameter of the pipe: 114mm
the material of the pipe: stainless steel
8. silo
volume: 1/0m3
the material of storage: stainless steel
9. control cabinet
schneider brand contactor, RKC temperature control instrument, made in Japan, inverter made in INVT brand. other electrical parts adopt siemens product.
Suzhou CMT, an international technology-oriented engineering group company, specialized in Turnkey Projects, technology consulting services and equipments manufacturing.
We have strong technical support. There are more than 2000 personnel in CMT, of which 60% are professional technicians. Around 50 are Middle and senior engineer and over 80 personnel own professional registered certificates.
The head office is located in Suzhou. It is equipped with more than 10 manufacturing bases all over China, spreading from Shanghai, Jiangsu, Shandong, Hebei, Hubei, Shanxi, etc. We are involved in many aspects, including Machinery, pharmaceutical chemicals, municipal utilities, power, electronics, building materials, energy saving, environmental pollution control projects, etc, offering project consulting, project designing, project managing, materials and equipments supply, project construction and running etc.
After all these years, our technology and service have been exported to more than 50 countries in the world, especially in Asia, the Middle East, Africa and the Americas, which earns us a great reputation. We adhere to the principle of "Quality first, service-orientation"and try to provide the best service. We warmly welcome you to our company and create brilliance together!
