Silicone Rubber Vulcanizer

Silicone Rubber Vulcanizer
Price: Negotiable/Piece
Trade Terms: CIF
Min Order: 1/Piece
Pay Type: L/C,T/T
1/. Automatic vulcanizer
Model: APM12, APM14, APM16, APM18, APM20
Automatic vulcanizer for curing silicone or organic rubber moulds for centrifgal casting.

Features:
1. Automatic control
2. Automatic pressure regulation.
2. Automatic temperature control
3. Curing cycle timer.
4. Automatic forced cooling
5. Digital display temperature and time.
6. Maximum pressure protection
7. Environmental and energy saving insulation design to provide a better temperature uniformity and Energy cost saving.

2/. Automatic vulcanier with PLC controller
Model: APM12-I, APM1-I4, APM16-I, APM18-I, APM20-I
Automatic vulcanizer for curing silicone or organic rubber moulds.

Features:

1. PLC Automatic intelligent vulcanizing control.
2. Touch-screen control panel.
3. Automatic pressure regulation.
4. Digital temperature controller.
5. Curing cycle timer.
6. Automatic forced cooling

7. Digital display pressure, temperature and time.
8. Maximum pressure protection
9. Hydraulic group with motor pump and oil pressure release valve.
10. Electro-valve controlled plate opening.
11. Environmental and energy saving insulation design to provide a better temperature uniformity and energy cost saving.

3/. Manual vulcanier
MVP12, MVP14, MVP16
Manual vucanizer press for curing silicone or organic rubber moulds for spin casting.
Features:
1. Automatic temperature control
2. Curing cycle timer.
3. Digital display temperature and time.
4. Heating plates with goods surfaces to assure perfect flatness.
Automatic vulcainer APM12 APM14 APM16 APM18 APM20
Mould diameter, max 12" 14" 16" 18" 20"
Mould thickness, max 150mm
Heating 6KW 6KW 9.6KW 10.8KW 15KW
motor 1.5KW
Pressure , max 32T 32T 50T 50T 50T
PLC automatic vulcanizer APM12-I APM14-I APM16-I APM18-I APM20-I
Mould diameter max 12" 14" 16" 18" 20"
Mould thickness, max 150mm
Heating 6KW 6KW 9.6KW 10.8KW 12KW
Motor 1.5KW
Pressure,max 32T 32T 50T 50T 50T
Model MVP12 MVP14 MVP16 MVP18 MV20
Mould diameter, max 12" 14" 16" 18" 20"
Mould thickness, max 150mm
Heating 4.0KW 6.0KW 9.6KW 10.8KW 12KW
Pressure , max 32T 32T 50T 50T 50T
Prod Model: APM12-I, APM14, VMP16
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Mould Diameter: 9", 12", 14", 16", 18", 20", 25"
Mould Thickness: 120mm Max
Processing: Automatic
Shenzhen kaite industry Co., Ltd. Specialized supply following items with high quality at reasonable prices from China.

Sand blasting / shot peening equipment and sandblasting media for shot peening, abrasive blasting, abrasive cleaning, garnet, glass bead, ceramic bead, plastic blast media, brown fused alumina, white aluminum oxide, steel shot, steel grit, casted stainless steel shot, zinc cut wire shot, seek cut wire shot, metal cut wire shot, metal blast media, sand blast nozzle, nozzle, pipe cleaning tool, pipe interior blaster, pipe interior cater, pipe cleaning equipment, etc.

Vibratory finishing equipments and consumable for deburring, readiusing, chamfering, grinding, descaling, burnishing, polishing of all types of components, abrasive chip, ceramic media, plastic media, porcelain media, vibratory finishing machine, centrifugal barrel finishing machine, centrifugal disc finishing machine, vibratory dryer, dryer, separator, tub finishing machine, stone processing machine .

Spin casting machines, centrifugal casting machines, vulcanizer, electric melter, silicone rubber

Traffic marking equipmets, paints, glass beads for road marking.
