PE/PP/PVC single wall corrugated pipe production line:
PE/PP/PVC single wall corrugated pipe production line is used to produce small diameter single wall corrugated hose. It consists of automatic feeding system/ single screw extruder/ die head / forming machine / winder. PE/PP/PVC single wall corrugated pipe is mainly used in the golf course, playgrounds as light load of drainage, floods; Interior decoration cable casing; Wire and cable threading pipe, washing machine drain pipe, vacuum cleaners, ventilation, air conditioning sewer; Prestressed concrete special-shaped tube
Features:
1. Once molding with relevant mould, corrugation is even and smooth.
2. Corrugated pipeline with4--6.7mm small aperture for auto, fill the domestic blank.
|
Extruder |
SJ-65/25 |
SJ-90/25 |
SJ-120/25 |
|
Diameter range |
Φ16-50 (mm) |
Φ65-115 (mm) |
Φ115-175 (mm) |
|
Water pressure |
0.4-0.6 (Mpa) |
0.4-0.6 (Mpa) |
0.4-0.6 (Mpa) |
|
Mould quantity |
40 (Pairs) |
50 (Pairs) |
60 (Pairs) |
|
Mould length |
2400 (mm) |
5180 (mm) |
6216 (mm) |
|
Speed |
1-8 (m/min) |
1-12 (m/min) |
1-8 (m/min) |
|
Dimension |
10×1.25×1.5(M) |
18×1.35×1.7(M) |
21×1.55×2.2(M) |
|
Weight |
3 (Ton) |
6 (Ton) |
9.5 (Ton) |
Qingdao Jinfuxin Plastic Machinery Co., Ltd is a state designated enterprise producing plastic machinery and high-tech enterprise in Qingdao. Mainly engaged in research & development, manufacturing, sales, and after-sale service of new plastic machinery. Products consist of PVC Crust Foam Board Production Line, Plastic Grass Mat Machine, PET/PP Strap Production Line, PA/PP/PE/PET/PBT Filament Extruding Machine, etc. And all kinds of plastic pipe, profiles, board, bar extrusion line and auxiliary equipment. Our machines are popular with the customers, which are sold all over the country and exported to Southeast Asia, Russia, Ukraine, Iran and other countries.
Since our company has establishd, it always takes the domestic and international market as the guide, the technology as leader, the quality as the life, strengthens joint units with domestic colleges and universities of science and technology and brings in and absorbs foreign advanced technology, in a timely manner to develop new plastic industry products according to the market demand, provides customers with a complete innovative set of production line, takes customer satisfaction as the ultimate goal, to strive for the best plastic machinery in China.
And expand the Qingdao Jin Xinquan Plastic Products Co., Ltd., production of plastic corrugated pipe products are mainly used for electrical threading pipe, auto threading pipe, casing, machine tool products, food packaging machinery, electric locomotives, engineering installation, lamps and lanterns, automation instruments and meters, etc
Jinfuxin company aim "morality for the surplus, credit management, service oriented, joint development, shaping the future".
