Sjpp-55 PP Film Extrusion Machine (CE)

Sjpp-55 PP Film Extrusion Machine (CE)
Price: US $ 13000-22000/Set
Trade Terms: FOB,CFR,CIF
Min Order: 1/Set
Pay Type: L/C,T/T
PP Film Blowing Machine
1. This screw material cylinder is elabroately made of 38CRMOALA alloy steel after nitrogen treatment and has best rigidity and corrosion resistance.
2. The mould head is plated with hard chroming and has screw mandrel structure with uniform and smooth material discharing. And the aircooled device has labyrinth lype structure with characteristic as uniform air-jut quantity, automatic temperature control and automatic heating.

OPTIONAL EQUIPMENT
1) AUTO LOADER
2) FILM SURFACE TREATER
3) DIE ROTARY DEVICE
4) AIR COMPRESSOR
Main Technical Variables:
Type

SJPP55

SJPP60

SJPP70

Diameter of screw

Φ55

Φ60

Φ70

L/D

28:1

28:1

28:1

Folding width of film(mm)

100-500

100-600

300-800

Single-face Thickness of film(mm)

0.01-0.1

0.01-0.1

0.01-0.1

Max. Extrusion(kg/h)

30

45

60

Power of main motor(kw)

11

15

18.5

Power of Traction motor(kw)

1.1

1.1

1.5

Length of Traction roller(mm)

550

650

850

Outline diameter(L×W×H)

4500×2000×3500

4800×2500×3800

5000×2800×4000

Weight(T)

3

4

5

Prod Model: SJ-PP
Markets: North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Type: PP Film Blowing Machine
Certification: CE
Automation: Automatic
Raw Material: PP
Computerized: Non-Computerized
Maximum Folding Width Of Film: 500mm
Screw Diameter: 55mm
Name: Ruian Fangtai Machinery Co., Ltd

Year Established: 1987

Registered asset: RMB81, 000, 000.00

Workers: 50-200

Management Personnel: 58

Technicians: 38

Chief Engineer: 10

Engineer: 38

Turnover: RMB100million (Year 2007)

The First Factory Area: 20, 000square meters

The Seconday Factory Area: 5, 000 square meters

Certificate: ISO9001, CE

Main Products: Flexo printing machines, casting machines, bubble film making machines, film blowing machines, computer control bag-making machines, slitting machines,

Principle: Good quality, best services, and competetive price

Market: East Europe, North America, South America, Asian, Africa, The Middle East, etc

Located city: Ruian city, Zhejiang Province, PR China
