1. Molding Silicone Rubber for Resin Craft (HY625) applications
Molding Silicone Rubber for Resin Craft (HY625) is primarily intended for poly resin crafts, PU crafts, PU resin crafts, gypsum crafts, unsaturated resin crafts, lighting and candles crafts, plastic toy, stationery gifts crafts industry, a large statue Buddha, furniture, furniture decorative materials, statues Buddha, artifacts copied, building decoration materials, large-scale cement mold, artificial fossils Factory, Europe component factory, simulation landscapes, animals and plants sculpture, sandstone crafts and so on.
2. Molding Silicone Rubber for Resin Craft (HY625) features description
Molding Silicone Rubber for Resin Craft (HY625) is white or red flowing liquid with general hardness of 22-50A° After curing. Molding silicon rubber is a kind elastic silicon rubber mold which features with easy operation, non-deformation, high-temperature resistance, acid-alkali resistance and expansion as well as high reproduction times, good tensile strength, tear strength and elongation.
3. Molding Silicone Rubber for Resin Craft (HY625) operations
If the customer wants to make large products and large size molds, the mold should be made of mold making silicone rubber with high hardness. On the contrary, if the mold with fine and precision patterns, it should be made of mold making silicon rubber with low hardness. The amount of the curing agent depends on the actual requirements of the customer. If molds requiring fast drying and demould, more curing agent is needed; Contrarily, if molds requiring slower drying and demould, less curing agent is needed.
(Note: Our company does not recommend you to add any silicone oil. If a special soft silicone mold or fine detailed and complex patterns products are required, 5%-10% silicone oil can be added to soften the mold for easy demould. )
4 Molding Silicone Rubber for Resin Craft (HY625) frequently asked questions
1. Why does the silicone rubber mold have few molding times?
The silicone rubber mold has few molding times is due to follwoing reasons: Adding too much silicone oil which will destroy the molecular of silicone rubber; Making the mold for small and fine detailed products with higher hardness silicone rubber which is easy to break; Making the mold for large products with soft silicone rubber which will reduce the tensile and tear strength of the mold, and the mold will have deformation. Thus, we should take the proper silicone rubber to make the mold for suitable products.
Any question pls feel free to ask us anytime.
| Model | 635# | 630# | 625# | 620# |
| Appearance | white | white | white | white |
| Mixing proportion of curing agent (%) | 5% | 5% | 5% | 5% |
| Operating time (mins 25 0C ) | 40~70 | 30~50 | 40~70 | 30~50 |
| Curing time(hours 25 0C) | 4~7 | 5~7 | 4~7 | 3~5 |
| Hardness (A°) | 35±2 | 30±2 | 25±2 | 20±2 |
| Viscosity (Mpas -25 0C) | 30000~38000 | 27000~32000 | 17000~19000 | 12000~14000 |
| Tensile-strength(Mpa) | ≥4.50 | ≥4.2 | ≥3.2 | ≥2.8 |
| Tear-strength (KN/m) | ≥30 | ≥30 | ≥27 | ≥32 |
| Elongation-break(%) | ≥420 | ≥440 | ≥440 | ≥420 |
| Linear Shrinkage (%) | ≤0.3 | ≤0.3 | ≤0.3 | ≤0.3 |
(Note : Other hardness can be provided to your requirements and silicone oil can be also provided to adjust the hardness and viscosity of silicone)
Certificate:
ISO900:2000
FDA
SGS
UL
RoHS
REACH
ISO9001: HK05/01358
SGS:GZ0606100461/CHEM
RoHS:BTRS091718751
Patent:ZL200520001597.8
Company Profile of Hong Ye Jie Silicone:
As a Leading manufacturer of liquid silicone rubber with more than 18 years,believed that we really can provide your the high-quality product with Competitive price,and even the technical support and perfect after-sales service.We really hope we can start an cooperation by giving both size chance . You get an chance for figure out an very good supplier ,We get the reputable partner for delevoping our silicone in your country.Let's do something good for your company in the future !
We are manufacturer spcializing in silicon rubber material, such as silicone gel, pad printing silicon, RTV-2 silicone rubber, HTV, RTV-2 room temperature sulfurated silicon rubber, silicon, shoe molding silicon, silicon rubber, manul molding silicon, liquid silicon rubber, LSR, pad printing silicone rubber, mixed iron-smelting silicon rubber, solid silicone rubber, methyl-ethenyl silicone rubber, molding silicone rubber, mold duplicating rubber for resin craft makers, special silicon for manual molding, shoe mold rubber, pad printing silicon, silicon oil, 107 base, DMC etc. For plastic toys factories. With a product line of tens of categories, we can offer quick copying with precise contraction ratio (up to two thousandth) for mold making. To reach the internationally leading quality standard with competitive price is our best ambition that merits your trust.
RTV-2 Mold making silicone rubber
[1] RTV-2 silicone rubber for mold making
RTV-2 molding silicone rubber mainly applicable to make the silicone mould for cultural relic duplication, architectural decoration, resin crafts, lighting ornaments, candles, statues, model design, product exploitation, etc.
[2 ]RTV-2 silicone rubber for pad printing
Pad printing silicon rubber is specially designed for silicon pads which requires to be exquisite, without impurity or granules. Silicon pad is a carrier which transfer printing the patterns on the steel plate onto the toy products' Surface. Pad printing silicone rubber is mainly used for printing irregular patterns of plastic toys, electroplating products, electronic toys, trademarks.
[3] RTV-2 manual mold silicon rubber
RTV-2 manual mold silicon rubber is mainly applied in manual mold design, PVC plastic mould, cement product mould, melting-point alloy mould, alloy toy crafts, plastic toy, craftwork, gift and stationery, big statue, cultural relic duplication, shoe sole mould production, pad printing orientation, electronic appliances vibration resistance, etc.
[4] HTV-2 Silicone rubber
HTV-2 silicone rubber is applied in metal crafts, hot stamping silicone roller, hot stamping silicone plate, mobile phone keycap, PC keycap, telephone keycap, TV remote control keycap, electronic products, silicone rubber products field, etc.
[5] Disc silicone rubber
Disc silicone rubber is mainly applicable to zinc aluminum alloy arts and crafts, imitation of gold and silver ornaments, fishing tools, bracelets, hanging ornaments, furniture fittings, decoration accessories, toys and gifts, etc.
