Advantages:
1)XIANGLE has steady world famous parts suppliers(Take-up Roller made in Tanwai, PLC is DELTA brand, made in Japan)
2)Design more scientic&reasonable
3)Save material, not occupy space
3)Power save, perfect performace
4)Bright, shiny &beautiful surface
5)20years experience, one and half hours to Shanghai Port
Main technical parameter:
Inlet wire: Φ 0.6mm
Outlet wire: Φ 0.2mm
Maximum number of drawing dies: 17
Maximum Line Speed: 200m/min
Control system: PLC Dual inverter control
Max. Dia. Of cone: Φ 230mm
Dia. Of capstan: Φ 253mm
Dia. Of take-up roller(Taiwan): Φ 200mm
Max. Amount of load wire: 15kg
Main power5.5kw
Take-up power: 1.5kw
Brake: Free brake
|
Inlet wire |
Φ0.6mm- |
|
Outlet wire |
Φ0.2mm |
|
Maximum number of drawing dies |
17 |
|
Maximum Line Speed |
200m/min |
|
Control system |
PLC Dual inverter control |
|
Max. Dia. of cone |
Φ230mm |
|
Dia.of capstan |
Φ253mm |
|
Dia.of take-up roller(Taiwan) |
Φ200mm |
|
Max.amount of load wire |
15kg |
|
Main power |
5.5kw |
|
Take-up power |
1.5kw |
|
Brake |
free brake |
|
|
|
Jiangyin Xiangle Machinery Manufacturing Co., Ltd. Has established itself as one of China's leading names in the field of Wire Drawing Machines, Annealing Furnace, and other related accessories with our promise of quality products that stay ahead of time.
Our main products are series stainless steel wire drawing machines, Spring wire drawing machine, annealing machine lines, take-up machines, copper wire drawing machine and other related equipments. We believe that perfect high-quality products only come from zero defect production process. We have adopted the advanced production equipment and technology, scientific & standardized management system and strict testing standards to ensure international advanced level on quality, structure, performance and appearance.
Our Management Concept
Quality is the life: To perfect quality is the continual goal of our company staffs all the time
Service is the key: To provide satisfying service is our responsibility.
Innovation is the power: Holding the concept of technology and innovation, we will try our best to develop new product.
Integrity is the principle: Seek truth from fact, manage company with good faith.
We make each component with all our mind and energy; Meet multiple requirements all from clients' interests. We hope to create mutual benefit with our clients!
Your choice, we care! . Please feel free to contact us for further information.
