Quick Details
- Condition: New
- Type: tire debeader
- Place of Origin: China (Mainland)
- Brand Name: JINKE
- Model Number: SL-1200
- After-sales Service Provided: Engineers available to service machinery overseas
- Color: any color
Packaging & Delivery
Packaging Details:Plastic film or as customer's requirment
Delivery Detail:35 days after receving the down payment
Specifications
1.Tire wire debeader
2.automatic
3.Capacity: 60~120pcs/h
4.CE
Application:
Draw out the steel wires from the tire bead.
Structural Features:
This machine consist of motor ,hydraulic system,drawing hook,drawingmouth,and main part,etc.its basic principle is Drien hydraulic system and made the cylinder work by the motor to make the drawing hook liked the cylinder spull pople reciprocate motion.put the tire on the drawingmonth and jut the drawing mouth to hook steel wire. meanwhile the rubber part of tire is teared because of the drawing mouth blick it.thus get the effect of separating smoothly.
Technical parameter:
1.Power:11Kw.
2.Cylinder moving:1200mm.
3.Tyre size:≤1200mm diameter.
4.Pull:13Tons.
5.Capacity: about 1000Kg/H.
6.Overall size: 3150*760*1120mm.
7.Weight:1200Kg.
Established in 1994s, JINKE Shredder Machinery Co., Ltd is located in the Jiang Yin City and is specialized in manufacturing Scrap tire recycling production line, Pulverizer and Crusher etc. Our products conform to international standards, such as CE, ISO9001: 2000. Our company covers an area of 12000 square meters, We enjoy convenient access to major transportation networks.
With an experienced and professional team, we have exported our productions to many counties and regions all over the world. Our productions enjoy a good reputation among our customers.
We welcome customers, business association and friends from all parts of the world to contact us and seek cooperation for mutual benefits.
