(1) Material of inlet wire: Low carbon steel wire
(2) Max. Strength of inletting wire: ≤700Mpa
(3) Max. Inlet wire diameter: Φ2.5mm
(4) Min. Outlet wire diameter: Φ0.6mm
(5) Max. Speed of drawing: 1000m/min
(6) Water consumption and hydraulic pressure: 3m3/h hydraulic; Pressure≥0.3Mpa
(7) Gas consumption: 0.6m3/h, air pressure≥0.4Mpa
(8) Electromotor:
A. Motor: 22KW AC electromotor (Wuxi Hengda)
B. Reeling machine: 15KW AC electromotor (Wuxi Hengda)
(9) Noise: ≤81dB
Main Technical Parameters
|
Specification
| NO. drawing
(mm)
| Max. Inlet wire
(mm)
| Min .Finished product
(mm)
| Motor
(kw)
| Speed
(m/s )
|
300
| 8-12
| 2.5
| 0.4
| 3-4.5
| 25
|
350
| 8-12
| 3.5
| 0.6
| 5.5-11
| 25
|
400
| 8-12
| 4.2
| 0.75
| 7.5-15
| 25
|
450
| 8-12
| 4.5
| 0.96
| 15-22
| 18
|
600
| 6-10
| 6.5
| 1.4
| 22-37
| 16
|
Jiangyin Sanheng Machine Co., Ltd successfully developed series production lines for MIG CO2 gas shielded welding wires, flux cored welding wires, stainless steel wires, high & low carbon wires as well as auxiliary machines and non-standard machines, which are not only meet customers' requirements but also in tune with the development of ferrous wires industry. Meanwhile, Sanheng is one stop for machine design, electric automation system, R&D, production, after-sales service and kinds of customized proposals.
As a specialized machine manufacturer, Sanheng is cooperating with many famous suppliers such as Siemens, Mitsubishi, which enable us to provide customers with efficient service and get good appraisal from customers.
Sanheng spares no efforts to become your most qualified partner.
