TF Starch Molding Linr Jelly Gummy Candy Making Machine

TF Starch Molding Linr Jelly Gummy Candy Making Machine
Price: US $ 30000-40000/Piece
Trade Terms: FOB
Min Order: 1/Piece
Pay Type: L/C,T/T
Automatic jelly/gummy candy production line

QQ(JelIy) candy processing line is an advanced and continuous plant for making different sizes of jelly candies (QQcandies). It is an ideal equipment which can produce out good quality products with the saving of both the manpower and the space occupied. This deposinting line consists of jacket dissolving cooker, gear pump, storage strainer, storage
Tank, discharging pump, color & flavor jigger, color & flavor mixer, depositor, cooling tunnel, e|ectric control cabinet, etc
The processing line is an advanced and continuous plant for making different sizes of gelatin-type soft candies(QQ candies). It is an ideal equipment which can produce out good quality products with the saving of both the manpower and the space occupied.
The processing line is advanced and continuous for making different size of gelatin-type soft candies (such as QQ candies). It is ideal equipment to produce high quality soft candies. With the sanitary structure design, on one hand it can produce one or two colors candy;
On the other hand, it can automatically blend the essence pigment and fermenting liquid in accurate quantity ratio. High-degree automation ensures of stable production and saves time and labor force and occupations to serve the purpose of reducing the cost.
FLOW CHART:
Sugar and gelatin dissolving mixing cooling transporting depositing cooling de-moulding following disposalà Packing

Wooden packing
1. Product production is completed, by the quality inspection department to check
2. After inspection qualified, clean for whole machine
3. Packing: A. Inside the machine put desiccant b. Add 6 cm thick foam plate around the machine, Then, winding stretch film for reinforcement, and combined with bubble wrap c. On wood packaging on the outside of the machine, then use metal reinforcement with steel
4. Container: According to different products for reinforcement


After-sale service for abroad customers.

1. Free training of macine installion, operation and maintenance will be provided by our engineer.
2. Some spare parts will be sent with the machine for free. It is available to buy the parts from us forever at low price.
3. We will surpport customers after-service forever by call, email and video etc.
4. If necessary, our engineer is available to go to customer's factory for machine installion and adjustment

Why choose us?

· Nearly 20 years experiences in food processing machinery production, established in 1982.

· We are manufacturer and wholesale of dough kneading machine

· We adopt environment-friendly materials and technology

· We mainly sell stock in bulk. OEM orders are welcome

· We can accept the mix order

Contact us

Shanghai SHINWEI machinery manufacturing Co., Ltd.
Add: No. 7151, Puwei Road, Huqiao, Fengxian, Shanghai, China 201417
Tel: +86-21-5745 0158
M/P: 13524622057
Fax: +86-21-5745 9003
Http://www.sh-xinwei.net
ModelGD150QGD300Q

GD450Q

Production capacity   ( kg/h)150300450
Rated depositing times(n/min)20~2520~2520~25
Weight of each candies(g):
1. two colors
2. single color

2g~.6g
1.5g~6g

2g~6g
1.5g~6g

2g~6g
1.5g~6g
Electric power needed8kw/380V12kw/380V16kw/380V
Refrigerator MT160 x1
15,000 kcal/h
10.5kw
MT160x2
30,000kcal/h
21kw
MT160x2
30,000kcal/h
21kw
Compressed air consumption
Compressed air pressure
0.20m3/min
0.4-0.6 Mpa
0. 25m3/min
0.4-0.6 Mpa
1. 25m3/min
0.4-0.6 Mpa
Conditions needed for
 the cooling system:
1.Room temperature
2.Humidity (%)


20~25
55


20~25
55


20~25
55
Conditions needed for
 the cooling system:
1.Room temperature
2.Humidity (%)


20~25
55


20~25
55


20~25
55
Length of the whole line   (m)9m11m15m
Gross weight           ( Kgs)Approx.3000Approx.4000Approx.5000
Prod Model: GD
Markets: South America,Eastern Europe,Southeast Asia,Oceania,Eastern Asia
Capacity: 600kg/H
Candy Weight: as The Candy Size
Depositing Speed: 55~65n/Min
Working Condition: Tempreture20~25 Humidity 55%
Power: 36kw/380V
Length: 22m
Gross Weight: 6000kg
Application: Candy
SHINWEI MACHINERY was from a company named Shanghai fengxian guyue food machine factory since year 1982which is a state owned enterprise for confectionery, chocolate, biscuit and packaging machinery. The founder of SHINWEI machinery is Mr. Wangzhiwei who is the director of guyue food machine factory till year 1995, after that year, the collective was restructured to Ltd and SHINWEI MACHIERY was established.

Nowadays, SHIWNEI always stand in the leader position in food machinery innovation and developing, the factory area is more than 6000square meters, five modern workshop, over 100 employees and has CNC machine, computer controlled lathe ect, in year 2005, SHINWEI PASSED ISO9001 authentication and most of the products passed European CE authentication. SHINWEI exported its products to east European, south America, Middle East, southeast Asia ect. District since year 2000, good quality products and perfect service makes SHINWEI have very good reputation and popularity.

SHINWEI MACHINERY provides not only the good quality production line for different kinds of confectionary production, but also the whole solution from making research, factory design, machinery installation and production, packing design ect. We are happy to cooperate with the new investor in food industry or experienced manufacturers. For more solution or information, please contact us or visit our website: http://www.sh-xinwei.net

With many years innovation and developing in food machinery design and manufacturing, SHINWEI always createa new and hi-tech products, such as the candy depositing line, after developing, the candy depositing line is controlled by servo driven equipment. SHINWEI's products is consists of hard candy, lollipop, soft chewy candy, jelly gummy candy, toffee candy, mashmallow, liquorice, chewy gum, bubble gum, chocolate production line and different kinds of packing machines, ect...

With many years innovation and developing in food machinery design and manufacturing, SHINWEI always createa new and hitech products, such as the candy depositing line, after developing, the candy depositing line is controlled by servo driven equipment.

SHINWEI's products is consists of hard candy, lollipop, soft chewy candy, jelly gummy candy, toffee candy, mashmallow, liquorice, chewy gum, bubble gum, chocolate production line and different kinds of packing machines, ect...
