Precise Horizontal and Vertical Milling Machine 6VH:
Fit for the semi-rough, precise pricessing.
Taiwan milling head and ball screw.
Power feed or machanic feed is optional.
Feathers and Characters:
1.Taiwan original milling head,NSK P4 spindle bearing;
2.Twice precisely scraping;
3.Head tilt angle ±45°/±90°;
4.OEM MANUFACTURER;
5.For electric parts, mould and hole, slot and frame processing;
6.Twice precisely scraping Fit for boring, milling, drilling and boring, tolerance is 0.005-0.012mm;
7.Spindle tolerance 0.002mm;
8.Parallel value between tables movement and table: X axis 0.015mm, Middle 0.01mm, Y axis 0.01mm.
9.Product parameter:
*Fit for semi-rough Processing , Precise Processing of the Medium and small parts
*Taiwan Original Precise Milling head, wide spreed range and high accuracy
*Sealed ballscrew , power feed or mechnical feed or servo motor are available
*Vertical milling , Horizontal Milling,+45.Slant Milling
| Model |
| 6VH-BC |
| Table size | mm | 1300x300 |
| Travel | Longitude | mm | 900 |
| Cross Ward | mm | 330 |
| Vertical | mm | 350 |
| Travel of Spindle Quill | mm | 140 |
| Max Distance from the spindle Nose to Table | mm | 450 |
| Quill Diameter | mm | ø 110 |
| Spindle | Rotation Speed | RMP | 75-3600(16 grades)/60HZ
60-820(9 grades(/60HZ) |
| Taper |
| NT40 |
| Rated Power | HP | 5 |
| Auto Feed rated | X axis | mm/min | 0-2000 |
| Y axis | mm/min | 0-2000 |
| Elevating Speed | mm/min | 1150 |
| Dimension | mm | 2200x2240x2370 |
| Net Weight | kg | 2750 |
| Max Loading | kg | 600 |
*Standard Accessories:
Way Cover
Working Light
Tool and Tool box
*Optional Accessories:
Clamping Kit
Milling Chuck
6" vise
Power Feed/Mechanical Feed
Elevating Motor
Coolnt Pump
Power Bar
