High quality c54 new product mini plastic injection moulding machine for India market
About company
We are the leading manufacture who specialize in designing and manufacturing different kinds of injection molding machine, with the experience of more than 20 years, manufacturing according to the ISO 9001: 2004 and CE quality control system guidelines. We help our customer develop special injection molding machine for the application and OEM service offered.
Product Description
Features:
Equipped with joint die structure of direct pressure and operation device of quick clamping and slowspeed locking with low pressure to ensure the safety of mold and fast speed and to increase production.
Special hydraulic injection structure with builtin pressure tracing compensation device to ensure quick injection rate and stable injection pressure and secondary injection pressure maintaining design to make products of high quality and high precision.
3 section temperature to control injection speed, back pressure and screw speed and achieve stepless adjustment. Suitable for all kinds of engineering plastic parts' molding.
Fixed bottom platen and movable upper platen to position insertion well. Equipped with ejector device for the finished product.
Equipped with Nitriding steel screw and feed pipe, high torque hydraulic motor drive and multi section injection pressure to create excellent plastify.
Equipped with electrical protection device to avoid wrong operation and ensure safety of repair.
Automatic lifting injection device and automatic cleaning device to make replacement of mold raw material easy.
Parameters :
| Model | Unit | LC-85T-X |
| INJECTION UNIT | Injection Cyclinder Diameter | mm | 35 |
| Theoretical Injection volume | cm3 | 134.6 |
| Screw Diameter | mm | 32 |
| Dposit Plastic Capacity | cm3 | 2500 |
| Injection Pressure | kgf/cm2 | 123/1260 |
| Injection Rate | cm3/s | 92 |
| CALMPING UNIT | Clamping Force | tf | 55 |
| Opening Storke | mm | 250 |
| Min Mold Height | mm | 260 |
| Max Daylight | mm | 510 |
| Platen Size (H×V) | mm | 540*490 |
| Overall Size of Slipform (H×V) | mm | 1050*500 |
| Distance Between Tie Bars | mm | 500*385 |
| Ejector Stroke | mm | 75 |
| Ejector Force | tf | 2.75 |
| OTHERS | System Pressure | kgf/cm2 | 140 |
| Oil Tank Capacity | L | 330 |
| Electric Power | kW(HP) | 15(20HP) |
| Machine Dimension (L×W×H) | mm |
2210*1750*3140 |
Machine Weight | ton | 3.8 |
Our service:
Pre-sale services:
1. Provide professional technical support.
2. Send the product catalog, instruction manual and detailed video.
3. If you have any question PLS contact us online or send us email, we promise we will give you a reply at the first time!
4. Personal call or visit is warmly welcome.
Sale of services:
1. We promise honesty and we can keep your mind the whole production and delivery process for your balers.
2. We guarantee punctuality, quality and quantities strictly implement the terms of contract.
3. Free training services for maintenance for you.
After-sale service:
1. Where to buy our products for half year warranty and long term maintenance.
2.24 hours telephone service online
3. Engineers are available to serve on your site.
FAQ
Q:Are you factory?
A:Yes, We are factory, all machine is made by ourselves and we can provide customize service according to your requirement.
Q:Where is your factory? Can I visit your factory?
A:Our factory is located on Dongguan city which near Shenzhen and Guangzhou City. We are warmly welcome you to visit our factory, we can pick you up when you come to Dongguan bus or train station.
Q:How to buy your machine?
A:Please send me inquiry to our email, when we reach a agreement, we will sign a contract to confirm our order.
Q:How to contact you?
A:You can click the "Contact Supplier" in the top of this page or contact me from the bottom contact info, we will reply to you via E-mail or phone call within 12 hours.
Q:What about your warranty?
A:Our warranty is 1 years, all machine part can be replaced for free within 1year if broken(not including man made).
Q:How long we will get the machine?
A:We and our clients usually choose the delivery by sea, so once you place the order, we will arrange the delivery within 3days, and about 7-35days(depend the destination port) you will get the machine.
Q:Are we still need to install the machine after we got?
A:We will debug the machine before we deliver to you, also we will send you video and manual to teach you how to use the machine. Besides, our engineer are available to provide you support how to install through remote teaching.
Q:How can you guarantee we receive a good quality?
A:First, we have Q/C department to control the quality. When the machine is finished,we will send you the inspection video and pictures. Or you can come to our factory to inspect the machine before you arrange shipment.
Within more than 10 years' development, Dongguan Chenghao machinery Co., Ltd is a professional manufacture of high grequency devices like plastic welding machine, synchronous fusing machines, blister machines and other high frequency mechanical accessories and molds. The increasingly competition in the industryispromoting us moving toward the goal of "rejuvenating the country, the industry and the market through quality, brand and reputation"
Except all kinds of machinery, the company also produces various auxiliary facilities. Together with its technical team, it helps customers develop leading products to meet different needs. "reserch and innovation, Pursuit of Excellence, quality First and World Based"condtitutes the company's quality policy. Chenghao machinery Co., Ltd warmly welcomes the sxisting and new customers from home and abroad. We are looking forwad to coopperating with you based on mutual reciprocity and mutual benefit for a better tomorrow, and we believe our cooperation will lead you to a great success.
