Wire Drawing Machine (SJ90/1100-250)
Price: |
US $ 105000/Set |
Trade Terms: |
FOB,EXW |
Min Order: |
1/Set |
Pay Type: |
T/T |
Researched and manufactured by adopting and assimilating German technology, together with the requirement for weaving technology of domestic market, Extrusion and Stretching Machines of this type controlled by micro-computer and frequency conversion governor have many traits such as high speed, high value, high efficiency and high automatic degree. They are widely used for producing container bags, small package bags, transparent bags and other PP and PE woven bags.
|
|
|
Model SSJ-280 Winder |
Seven-Roller for Stretching,Forming,
Retracting and Water Cooling |
Electrical Control System |
|
Model |
BSJ90/1100-250
|
BSJ120/1500-220
|
BSJ150/1200-200
|
Suitable material
|
PP/HDPE
|
PP/HDPE
|
PP/HDPE
|
MaxExtrusion output
|
280kg/h
|
420kg/h
|
600kg/h
|
L/D Ratio of Screw
|
30:1
|
33:1
|
Purging Screw Tube
|
Rotational Velocity of screw
|
20-120r/min
|
20-140r/min
|
20-120r/min
|
Width of Die Lip
|
1100mm
|
1500mm
|
1200mm×2
|
Filter Form
|
Automatic belt filter
|
Automatic belt filter
|
Automatic belt filter
|
Stretching form
|
Up and down double face hot oven (Hot bowed board oven, electricity heating
|
Up and down double face hot oven (Hot bowed board oven, electricity heating
|
Up and down double face hot oven (Hot bowed board oven, electricity heating
|
Quantity of Equipped Spindles
|
184 spindles
|
256 spindles
|
400spindles
|
Max Linear Speed
|
250m/min
|
250m/min
|
220m/min
|
Density Scope of Flat Film
|
60-220tex
|
60-220tex
|
60-220tex
|
Total Power
|
260kw
|
400kw
|
420kw
|
Measurement
|
36m×5m×3.6m
|
44m×5m×3.6m
|
(35-50)m×5m×3.6m
|
Total Weight
|
24T
|
34T
|
35T
|
Introductions: Standards of Flat Film: 2 .5mm, Thickness of Film:About0.05m
|
Prod Model: |
SJ90/1100-250 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Automation: |
Automatic |
Raw Material: |
PP |
Type: |
Flat Wire Drawing Machine |
Computerized: |
Computerized |
Mode: |
Horizontal |
Anhui Tiandi Plastic Machinery Co., Ltd. is located in Tianchang city, the land of fish and rice, about 50 km away from Nanjing and Yangzhou. As "High-tech Enterprise" in Anhui Province, established in 1991, it specializes in the manufacturing of plastic weaving facilities (formerly known as Anhui Tianda Group Plastic Machinery Branch). In 2001, it took the lead in introducing foreign capital and technology and was reorganized into a private holding company with an area of 220 mu, a registered capital of RMB 26 million and fixed assets of RMB 120 million. Its main products are listed below: 1. High-speed Four Shuttle Circular Weaving Machine; 2. Small Six Shuttle Circular Weaving Machine (rubbing, trolley wheel and roller); 3. Medium Six Shuttle Circular Weaving Machine; 4. Large Six Shuttle Circular Weaving Machine, Large 8-12 Shuttle Circular Weaving Machine; 5. High-speed PE Film Ribbon-like Filament Wire Drawing Machine; 6. Interior Coating Film Facility and Automatic Cutting & Sewing Machine; 7. Cloth Laying Machine; 8. Bag Cutting Machine; 9. Wrapping Machine.
Meanwhile, we provide "One-stop" production line design for customers, all-round staff technology training as well as the upgrading and reconstruction of some identical equipment in Changzhou and Zhejiang.
Under the principle of high starting point and heavy investment, it has introduced all kinds of production test facilities including processing center, three-coordinate measuring machine and metallographic analyzer, etc. With an annual production and sales capacity of almost 1000 weaving facilities, it has become the most influential domestic star in the industry from the former complementary company. By relying on talent advantages, it has developed a new type of high-speed and small Six Shuttle Plastic Circular Weaving Machine (trolley wheel and roller) and PE Film Ribbon-like Filament Wire Drawing Internal Laminating Machine. These two products were qualified with the achievement appraisal of Anhui Science & Technology Bureau on Nov. 12th, 2004. Such achievement filled in the gaps in Anhui and reached the leading level of the domestic like products. Meanwhile, its many products and designs have obtained various national utility model patents and invention patents.
In the tenet of "First-rate Quality, First-rate Credit" and under the guidance of IS09001: 2000 Quality Management System, it has established a powerful after-sales service system with 21 assembling and debugging personnel with professional quality. Its products sell well in both domestic markets and foreign countries and regions including Africa, Indonesia, Malaysia, Middle East, North America, Thailand, Russia and USA, etc., winning the favor of customers at home and abroad due to its high-quality and excellent after-sales services.
The technology and process of the company are reasonable and mature. In addition, the Circular Weaving Machine and Wire Drawing Machine are developed by the company with independent intellectual property rights and take the lead in the same domestic industry. The company has solid comprehensive power and industrial foundation. We believe that our company will surely have broader development space and more powerful development potential in the near future.
