Wire drawing machine
We adopt optimized cone twin screw, which makes the extruder has good performance in melting and stability of manufacturing, meanwhile, the superior gear box is remarkable in its torsion, lifespan and low noise control. The drive motor is AC National Standard.
1)Model: SJZ-65/132
2)Screw
Brand: GUANGYOU (Famous brand)
Diameter: 65/132mm
Material: 38CrMoAlA
Origin: China ZHEJIANG
3)Barrel:
Brand: GUANGYOU (Famous brand)
Material: 38CrMoAlA
Origin: China ZHEJIANG
Internal Surface Processing: Nitriding, Honing, Hard-facing
Heating Zone: 4 Zone
Heating method: Cast Aluminum and stainless steel cover
Heating Power: 18KW
Cooling System: Barrel air cooling
Cooling Power: 0.18KW× 3
Head Flange heating method: Mica Heating Ring
Head Flange heating power: 2.5KW
4)Reduction Gear Box
Brand: JC
Origin: China JC
Material of the tank: HT200
Gear Style: Spiral gear
Gear Material: 20CrMnTi
Gear Surfacing: Quenching
Material of Screws: 40Cr
Cooling System: Internal Water Recycle
5)Drive Motor
Motor Power: AC 30KW
Motor Type: International energy saving motor
Motor Control: Frequency Changer (JANPEN FUJI/Toshiba)
6)Feeding Device
Feeding: Springs
Feeding Motor Power: 0.4KW
Speeding model: Frequency changer (JANPEN FUJI/Toshiba)
7)Vacuum Exhaust system
Power of Vacuum Exhaust Pump: 1.5Kw
Limiting Vacuum: -0.093Mpa
8)Distribution Box Control System
Temperature control display: APEN RKC/ Omron
Temperature Control Zone: 11 Zone
Contactor: FRANCH SCHNEIDER
Breaker: FRANCH SCHNEIDER
Switch: Taiwan TAIWAY ELECTRIC
Potentiometer: JAPEN SAKAE
Button/Switch: Shanghai SINYI
Frequency Changer: JANPEN FUJI/Toshiba
Langfang Xinming Cable Machinery Industrial Co., Ltd. is founded in August, 1984, with an area of 25000 square meters and the staff of 200 persons, including 2 senior engineers, 6 engineers, and 100 technicians. It's the professional manufacturer for the electrical wire and cable machinery facility. In October, 2005, the company sets up the copper clad aluminum workshop with 100 different high-speed wire-drawing machines. And the factory is situated in West of Road, South of the Shige Village Toll Bridge in 106 National Highway, Wen'an County, Hebei Province. The geographical position is superior and the transportation is convenient. Now the company has strong technical force. The main products of the company are: High-speed extruder SJ50, SJ70, high-speed multi-function automatic whipping (whisking) machine, SJ30\SJ45\SJ65\SJ90\SJ120\SJ150\SJ200plastic extruder full-set production line, cable-former and so on. And the products are popular among the general customers.
Besides, the company has researched CCA (M) according to the standard of developed country at aboard. And the products have the same merits as the copper: Good conductivity, high intensity, strong welds ability, easy-processing, etc. Moreover, these products have more advantages than the copper: Light weight, soft wire, low cost, etc. So the CCA can be widely used in the CATV, net wire, communication cable with large capacity, control cable, power cable, etc.
The company set up complete technology department, test department and after-service department with the operation guideline of good credit and superior quality. And there are many excellent technicians with positive enterprise idea. Moreover, the enterprise spirit is development, cooperation and innovation.
Our management policy: "customer-centric, market-headed, science-guided, management-guaranteed". Our enterprise spirit: Practicality, efficiency, development, innovation. Our aim is to meet customers' requirement and get customers' trust. Our tenet: High-quality product, reasonable price, in-time delivery, complete after-service. Our logos: Development, cooperation, innovation.
Sincerely welcome you for business! Let's cooperation for the brilliant future!
