Dia of takeup wheel: 560mm
Draw die: 1-6
Max. Incoming diameter: 6.5mm
Outgoing diameter: 2mm
Total compressibility: 78--88.5
Average partial compressibility: 30%
Drawing speed: 245
Motor power: 60-80KW
Overall dimension: 1700x1150x1750mm
Weight: 2000KGmm
XIND Wire Mesh Machinery Co. Ltd is a manufacturer and exporter of wire mesh machine, Expanded Metal Mesh Machine, Welded Wire Mesh Machine, Three Dimensional Panel Machine, Hexagonal Wire Netting mesh Machine, wire mesh cutting machine, Insect Screen Wire Netting Machine, Square Opening Wire Mesh Weaving Machine.
