| Price: | US $ 3000-5000/Piece |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 1/Piece |
| Pay Type: | T/T,Paypal,Western Union |
NO. | Model | OD1290 |
1 | Laser medium | CO2 |
2 | Working area | 1200*900mm or optional |
3 | Working table | Knife table or honey comb table |
4 | Laser power | 80W, 100w, 130w, 150w, etc. |
5 | Power Supply | 220V/50Hz, 110V/60Hz |
6 | Min line width | ≤0.15mm |
7 | Positon accuracy | 0.01mm |
8 | Repetition accuracy | 0.02mm |
9 | Cutting speed | 150mm/s |
10 | Guide rail | Hiwin from Taiwan |
11 | Transmission method | Belt Transmission |
12 | Drive system | Leadshine driving system and stepper motor |
13 | Cooling system | Water-cooling |
14 | Control system | RD6442G color control panel |
15 | Control software | Coreldraw, Photoshop, AutoCAD, Tajima |
16 | Graphic format support | PLT, DXF, BMP, JPG ,AI and ect |
17 | Working environment | 0-45°C, |
18 | Operating Humidity | 5-95% |
19 | Gross Power | 220KG |
20 | Net weight | 300KG |
21 | Dimensions | 1530*1210*1560mm |
22 | Optional Parts | Honey nest table USB Feature Up-down work table Auto focus Rotary System |
| Prod Model: | OD-1290 |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Laser Power: | 80W CO2 Laser Tube |
| Warranty Time: | Laser Tube Is 6 Month ,Other Is 1 Year |
| Delivery Time: | 7 Days |
