Product Description
We are professional manufacturer & exporter a wide range of hydraulic automatic injection molding machines over 20 years, clamping force from 600 to 32000KN, injection weight from 68g to 40570g. Our machines are known for the features like durability & sturdy construction.
We have ordinary, servo motor energy saving, variable pump and high speed series.
Products of suprior quality and competitive price are our steadfast guarantee to our customers.
Product Description LONGSHENG Machine Advantage: 1) Guarnateed for two years 2) Offer Injection Machine Operation&trainning video 3)LONGSHENG have SGS certificate 4) T-Slot Platen 5)machine weight much more than most of factory 6)machine base use rectangular tube, more strong 7)four PCS safe door are moveable, maintain the machine more convenience 8)Hydraulic Tank is moveable, more easy to clean the tank when needed 9)Heating band is made by ceramics, not steel sheet. Can work more long time; 10)Prepared more spare parts for customer as below: 2PCS nozzle; 1 set tool box; 3PCS heating band; 1 set mold clamp; 1 container lubricate oil; 1 PC oil filter; 2 PCS switch; 1 set HEX spanner; Seal circle: 3PCS 11)LONGSHENG Injection Machine computer with USB connect Point, you can move all mould settings parameter on your desktop computer Additional Info. Trademark: LONGSHENG Packing: Plastic Film Origin: China HS Code: 8477101090 Production Capacity: 500sets/Year
INJECTION UNIT
item
unit
LS-1680
A
B
C
screw diameter
mm
120
130
140
screw L/D ratio
L/D
25.6
23.6
22
theoretical shot size
cm 3
8821
10353
12007
injection weight
g
7939
9317
10806
Injection rate
g/s
1103
1190
1307
Plasticizing capacity
g/s
146
155
163
Injection pressure
Mpa
213
181
156
Screw speed
rpm
0-100
CLAMPING UNIT
Clamp force
KN
16800
Space between tie bars
mm
1520*1480
Toggle stroke
mm
1560
Max. mold height
mm
1550
Min. mold height
mm
720
Ejector stroke
mm
400
Ejector tonnage
KN
328
Ejector number
p
29
OTHERS
Max.pump pressure
Mpa
16
Pump motor power
KW
45+45+45
Heater power
KW
94
Machine dimension
m
16.5*3.2*5.2
Machine weight
t
115
Changzhou Longsheng Machinery Co., Ltd locates in Zhonglou Scientech Industry Park of Changzhou, mainly produces and sells Plastic Injection Molding Machine, with high technology and reliable quality, our products are selling all over the world. We compare the price with the same quality, while compare quality with the same price, compare the service with the same quality and price, we regard it as our management tenet. We always integrate the optimized design associated with manufacture and good sales service together. We adopt 24hours-networking for sales service, all lifecycle services for products, smile is our characteristc service.
Ways to success, start from Longsheng. Longsheng Possesses solid strength, devoted to create a brand name ---Longsheng Machinery Series. The Clamp Force of our machines range from 600KN to 16800KN, Shot Weight range from 63G to 10000g, Plastic Injection Molding Machine is widely applied in the areas of automobile, mechanical, chemical, electrical, daily supplies, toys, etc.
