Model:
SA-4
Machine Brand:
Yls
Cavity:
4-6
Condition:
New
Raw Material:
PET
Making Method Of Parison:
Extrusion-Blow Molding
Automation:
Automatic
Computerized:
Computerized
Certification:
QS
Product Description
ERUSUN-SA series blow moulding machine is the latest high output semi-automatic PET blow moulding machine. Comparing to the traditional machine design, thanks to new concept of automatic bottle discharging unit, the patented heating system and the preforms automatic loading design, The SA series blow molding machine requires less manpower and reducing the work intension for the operator. New SA series blow moulding machine holds the cavity of the blowing mold up to 6 cavities, the output reaches 1800BPH for 500ml water bottles. Compared to the output of normal manual blow moulding machine, this is an outstanding improvement in the PET Bottle blow molding industry.
M odel
SA 4
SA6
Number of Cavities
4Cavity
6Cavity
Material
PET/PC/PP/PE
PET/PC/PP/PE
Clamping Force
180KN
300KN
Max Clamping Stroke
350mm
250mm
Bottom Moving Stroke
60mm
60mm
Max. Stretching Stroke
380mm
380mm
Theoretical Output
2000BPH
2800BPH
Max. area of mould base
620*420mm
750*420mm
Max. Mould Thickness
190mm
190mm
Space Between Tie Bars
550*340mm
670*340mm
Electrical system
Voltage Standard
380v/3PH/50Hz or special order
Total power(Full Loaded)
15KW
18KW
Container
Max l ength of preform
180mm
180mm
Diameter of preform
15mm-40mm
15mm-40mm
Container Volume
0.1-2.5L
0.1-1.0L
Diameter of neck finish
15mm-45mm
15mm-30mm
Container Diameter
110mm
70mm
Max. Height of container
370mm
250mm
Air system
High pressure Air compressor
>1.2m /3.0MPax23 (0.5L)
Dimension & Weight
Blow molding machine
1.9*0.88*1.8M
Oven
1.9*0.66*1.6M
Net Weight
1.3T
ZHANGJIAGANG ERUSUN MACHINERY Co., Ltd. is one of the leading providers of liquid packing solution, for drinking water, carbonated soft drinks, juice drink, tea drink, energy drink, milk drink, alcoholic beverages, beer, and edible oil, packed in plastic bottles, glass bottles, pop-top cans, cups, sachets, stand-up pouch and etc.
ERUSUN is in this business for over 10years, have installed our filling line in more than 30 countries and regions, such as Russia, Armenia, Ukraine, Uzbekistan, Kazakhstan, Kyrgyzstan, South Africa, Mexico, Peru, Singapore, Canada, Malaysia, Thailand, Indonesia, Vietnam, India, Pakistan, Iraq, Iran, Lebanon, Nigeria, Tanzania, Sudan, Kenya, and so on.
We offer flexible and reliable filling machines that are easily adaptable to market developments and future technology, supported by value-added services. We are committed to being an innovative, responsive and reliable partner, providing sustainable solutions for the beverage industry.
Cooperate with us to get a bright future together, Our Products, Your Industry!
