| Prod Model: |
787MM |
| Markets: |
South America,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia |
| Raw Material: |
Virgin Pulp, Waste Paper |
| Model: |
787mm |
| Capacity: |
1t/D |
| Process: |
Paper Machine |
| Usage: |
Office Paper Machine |
| Automatic Grade: |
Automatic |
| Computerized: |
Yes |
| Paper Thickness: |
Normal Specification Paper |
| Condition: |
New |
| Type: |
Paper Processing |
| Certification: |
ISO |
Product Description
I. Technical parameter:
Adapt pulp: Waste paper pulp, wood pulp
Output paper: Xerox paper, culture paper, writing paper, newsprint paper
Weight: 40-120G/M2
Net paper width: 787mm
Capacity: 0.8-1.2T/D
Rail gauge: 1300mm
Drive way: AC Drive Motor
II: Main frame of the equipments:
Cylinder part: Two cylinder moulds(Φ 700mm× 1000mm). Three couch rolls(Φ 250mm× 1100mm), include one reverse roll. Rubber hardness HS-380± 2
Press part: Upper roll: One natural marble roll. One rubber roll(Φ 2600× 1100mm), rubber hardness HS-90° ± 2, pneumatic loading mechanism.
Dryer part: Two dry cylinders(Φ 1000× 1100mm), one touch roll(Φ 260× 1100mm). Rubber hardness HS-90° ± 2, mechanical loading. Cylinder part two equipped with one Anti-roll, mechanical loading.
Reeling part: One cooling cylinder(400× 1100mm), reeling paper by the cylinder.
About paper-making
This production line can use waster paper,recycled paper ,tree ,bamboo ,reed ,wheat straw cotton and bagasse as raw material to make good quality craft paper,finished product can be paper roll, tissue paper, toilet paper, culture paper , Kraft paper, newspaper etcthe main work flow is as follows:
1 pulp making production line
2 glue adding system
3 paper making production line
4 paper converting section
5 boiler section
