Production Name:
Blow Molding Machine for Plastic Panel
Usage:
Big Plastic Panel Forming
Type:
Extrusion Blow Molding Machine
Making Method Of Parison:
Extrusion-Blow Molding
Automation:
Automatic
Computerized:
Computerized
Raw Material:
PP,PE,HDPE...
Certification:
CE,SGS,ISO9001
Product Description
Blow molding machine for plastic panel
Good quality and best price can make your needs
It is a special machines used for producing products with High Molecular Weight High Density Polyethylene (HMWHDPE) as the raw material, including oversize plastic wall panels,door panels,ocean buoys,safety barriers for highway,athletic equipments,and plastic products of recreational facilities.The machines is designed and manufactured in accordance with standards of similar machine models of Germany,and this machine model has the optimized performance price ratio in the world.
TDB160E is an accumulation and injection type extrusion blow molding machine which can produce plastic door panels and plastic desktop panels.It has reasonable structure and steady and reliable performance.
Item
Code Item
Standard Code
Manual
Extruder (Main extruder)
Max. capacity
160L
Main screw
φ100mm
High efficiency of mixing
Screw L/D
28: 1
Screw material
38CrMoALA
Max. extruder consumption
200KG/Hr
Take HDPE for example, change with material density
Twisting transition method
Electrical FESTO, Germany machinery, Gear box, Leather belt transmission
Hard gear surface decelerator
Driving motor
75KW
Screw rotate speed
10---70r/min
Ahead/back adjusting
Yes
Up/down adjusting
Yes
Temperature control zone
5
Japan MTSUBISHI
Heating power
4φ9.5KW
Cooling for blower
4
Cooling function
Yes
Cooling water
Clamping unit (Mold opening/closing unit)
Structure
With patented TONGDA two-bar timing clamping structure in high speed and high force, to achieve quality products.
Clamping directions
Ball rail
For high precise location for longer service life.
Cooling effect is achieved by oil pressure cooling
Mold cooling
Separated cooling water resource, use 5-in 5-out fix (single side)
Gear box, hopper place, die dimension cooling
Use separated cooling water circuit, insure cooling effect
Overall dimension
L*W*H
5930*3000*5600mm
Weight
TON
22.0T
Zhangjiagang Sino-tech Machinery Co., Ltd. is a group company located in the beautiful seaport city of Zhangjiagang, which is near to Shanghai. We devote ourselves to the development, research and production of plastic machine, beverage equipments filling and packing industry and automatic blow molding machine with over 20 years'experience.
Now our equipments have been exported to USA, Canada, Mexico, Colombia, Brazil, Argentina, UK, France, Germany, Belgium, Russia, Saudi Arabia, UAE, Yemen, Iran, Oman, Syria, Jordan, Israel, Egypt, Japan, Philippines, Myanmar, and India etc...
For plastic machine: , Our main products include as follow
Big-mouth PVC pipe excluding production line
PE big-mouth for gas, water supply excluding production line
Plastic sheet or panel production lin
Plastic profile production line
Plastic granulating production line
Plastic recycling machine
PP-R pipe production line
Plastics extruder
High speed mixer, various plastic auxiliary machines
For beverage machine, our Main products include as follow
The capacity of 2000-- 40000 BPH for mineral water and purified water producing line.
The capacity of 2000-- 40000 BPH for hot filling, MID-temp filling, aseptic cold filling lines.
The capacity of 2000 -- 36000 BPH for carbonated beverage producing line.
The capacity of 300 -- 1200BBH 3 gallon, 5 gallon barrel filling line
The capacity of 1000 -- 12000BBH glass bottle beer filling line
The capacity of 2000 -- 25000BH ice pop, ice lolly filling production line
Various kinds of linear and rotary engine oil and edible oil filling line
All kinds of water treatment equipment.
PET perform injection and blowing-stretching machine.
Extrusion blow molding machine
Turn-key projects
Flat and tube UHT device, and CIP system.
SINO-TECH purpose is "keep developing to meet worldwide clients' demands. "
Welcome to visit our company. Thank you!
