PP.PE Products:
50L
Automation:
Automatic
Making Method Of Parison:
Extrusion-Blow Molding
Raw Material:
HDPE
Computerized:
Computerized
Certification:
CE
Product Description
Zhangjiagang Stone Mechanical Equipment Co., Ltd. is a professional company located in Zhang JiaGang city, we have more than 20years experiences in plastic machinery and beverage filling machines Industry.
We devote ourselves to the products development, research, implode and make new products for plastic machine, liquid food, beverage packing and filling industry in China.
For plastic industry our main products include:
A. Hollow plastic products blow molding machine products volume from 0.5ml to 10000L
B. Plastic extrusion line
C. Injection machine
D. PET blow molding machine
E. Plastic product
General information
Material
STBM-A30L
STBM-A60L
STBM-A120L
STBM-A220L
HDPE, PP
HDPE, PP
HDPE, PP
HDPE, PP
Max products
30L
60L
120L
220L
Idle cycle
300PC/HR
300PC/HR
300PC/HR
300PC/HR
Size (M)
4.4x2.5x3.8
5.2x2.9x4.6
5.7x3.1x4.85
7.5x3x6
Weight(Ton)
10.5
14
17
30
Total power(Kw)
93
125
152
207KW
Average
Consume(Kw)
35
52
63
124KW
Extruder
Diameter
75/80
90
100
Φ 120mm
L/D
25:!
25: 1
25: 1
30
Cap kg/h (PE5502)
100
170
200
350
Barrel Heating zone
4?
4
5
5
Barrel Heating power
19
26
31
35KW
Extruder motor power
30
45
55
132KW DC
Die head
Die head volume (L)
4.4
6L
10L
20L
Max extrusion speed(kg/sec)
1
1.5
1.8
3.5
Die head Heating zone
4
4
5
6
Heating power
17
20
25
35KW
Max die nozzle(mm)
200
320
450
Φ 450mm
Min die nozzle (mm)
85
100
120
120
Clamping
Clamping force(KN)
200
250
510
750KN
Plate distance(mm)
250-800
450-1100
500-1350
650-~1850
Plate size(w× h)
750x650
900x800
1100x1300
1300× 1400
Blowing
Blowing pin stroke (mm)
150
150
150
150
Frame up and down (MM)
250
250
250
250
Robot
Working stroke (MM)
1000
1000
1000
1000
up platform
Stroke (MM)
350
400
450
450
Speed (mm/min )
30
30
30
30
Hydraulic
Oil pump motor
22
30
37
45KW
Big pump volume (L/Min)
12
266
Small pump (L/Min)
16
40
Thickness controller hydraulic
Moog 100 point
Moog 100 point
Moog 100 point
Moog 100 point
Pressure Mpa
14
14
14
Flu volume (L/min)
23
23
23
Pump power (KW)
4
5.5
7.5
Pneumatic
Source pressure (Mpa)
0.8
0.8-1
1
1Mpa
Working Pressure (Mpa)
0.6
0.7
0.7
0.8 Mpa
Consumption (M 3 /min)
0.4
0.6
1
2
water
Pressure (MPa)
0.2~0.3
0.2~0.3
0.2~0.3
0.2~0.3
Flux (L/min)
200
200
300
400
electrical
Temperature controller
Data communication
Data communication
Data communication
Data communication
Crafts time
Data communication
Data communication
Data communication
Data communication
Power
AC380V± 10% 50HZ
AC380V± 10% 50HZ
AC380V± 10% 50HZ
AC380V± 10% 50HZ
Phase
Three phase
five wires
Three phase
five wires
Three phase
five wires
Three phase
five wires
Zhang Jia Gang Stone Mechanical Equipment COM., Ltd Is a professional company located in Zhang JiaGang city, we have more than 20years experiences in plastic machinery and beverage filling machines Industry.
We devote ourselves to the products development, research, implode and make new products for plastic machine, liquid food, beverage packing and filling industry in China.
For plastic industry our main products include:
A. Hollow plastic products blow molding machine products volume from 0.5ml to 10000L it's including:
1)STBM-CS2L----------------STBM-CS12L
2)STBM-CD2L----------------STBM-CD10L
3)STBM-CD15L--------------STBM-CD25L
4)STBM-A30L-----------------STBM5000L
5)Plastic mold injection and blowing
B. Plastic extrusion line
1) PVC pipe excluding production line
2) PE big-mouth for gas, water supply excluding production line
3)Plastic sheet or panel production line
4)Plastic profile production line
5)Plastic granulating production line
6)Plastic recycling machine
7)PP-R pipe production line
8)Plastics extruder High speed mixer, various plastic auxiliary machines
C. Injection machine
From 10Ton-900Ton horizontal injection
D. PET blow molding machine
1) STPBM S6-S8 Semiautomatic for 150ml-2000ml
2). STPBMS9A Semiautomatic for 2L-5L
3). STPBMS9B Semiautomatic for 5-12L
4). STPBM5G 5 gallon PET blow molding machine
5) STPBM A6 automatic pet blow molding machine
6) PET preform and blow molds
E. Plastic product
IBC container, pallet. 220L drums, cool boxes and plastic material
For beverage and filling industry including:
1). The capacity of 3000-- 25000 BPH for hot filling, MID-temp filling, aseptic cold filling lines.
2). The capacity of 3000-- 25000 BPH for mineral water and purified water producing line.
3). The capacity of 3000 -- 25000 BPH for carbonated beverage producing line.
4). The capacity of 300 -- 1000 TBH, for 3 gallon, 5 gallon.
5). The capacity of 8000 BPH for the volume of 200ml to 500ml in milk packaging.
6). All kinds of water treatment equipment.
All the products are sold well in China and also exported to more than thirty countries and areas. Strong technical support, advanced equipment, scientific management system and perfect after-sales service for we get more clients and market We are sure choose us can make you business further improvement.
We are not only manufacturing a kind of products, also creating a kind of
Culture. The originality of our products derives from our profound understanding
Of the culture and will to develop the machinery industry
We sincerely hope establishing long and friendly business relations with clients from all over the world. Our goal is not just providing product, but also providing a complete solution including product design, tooling, fabrication and service for our customers to achieve their upmost satisfaction.
We stick to the principle of "quality first, service first, continuous improvement and innovation to meet the customers" for the management and "zero defect, zero complaints" as the quality objective. To perfect our service, we provide the products with the good quality at the reasonable price.
Our company has always insisted on relying quality to seek survival, benefit to seek development. Use fine after-sale service to meet the needs of consumers. Honesty and credit. Products are sold well all over our country. Warmly welcome all fields of friends to visit our company and negotiate trade.
Our service is after get you information during 24 hour give you clear reply and solution
Our aim is you satisfy is my pleasure
Our purpose is friend always important than business
Wish you and us win win
