| Prod Model: |
LTQT10-15 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Processing: |
Brick Molding Machine |
| Product: |
Solid/Hollow/Paving Brick |
| Brick Raw Material: |
Concrete |
| Automation Degree: |
Fully Automatic |
| Condition: |
Brand New |
| After-Sale Service: |
Engineers Are Available to Overseas |
| Size: |
8100*2000*3000 mm |
| Power: |
41kw |
| Rated Operating Pressure: |
12-25MPa |
| Pllet Size: |
1150*950*30 |
| Type: |
Concrete Iron Molding Machinery |
Product Description
Product description
T10-15 block making machine belong to general equipment for concrete blocks, and can be used to
produce a variety of concrete wall blocks by the replacement of molds, such as new thermal-insulation
bricks, hollow bricks, multi-hole bricks, solid bricks and so on, all kinds of paving blocks such as
interlocking bricks, Dutch bricks and paving stones, and a variety of special concrete elements, hydraulic blocks, dry-bonded bricks, planter bricks, palisade bricks for parks, airports, docks and other purposes.
The machine is applicable for the manufacture of high-quality and high-strength concrete or fly ash
blocks,and is the most advanced and the most reliable model in the domestic market. The company
has production lines of different configurations to meet the processing requirements and production
needs of users for most concrete products.
Introduce of LTQT10-15 Hydraulic Automatic Block Making Machine
Technical Parameters
Technical parameters |
Dimensions of main frame(L*W*H) |
8100*2000*3000mm |
Molding height |
50-190mm |
System pressure |
25Mpa |
Virbration forcement |
100KN |
Dimension of pallet |
1150*950*30mm |
Whole weight |
17000KG |
Molding cycle |
15s |
Power of main frame |
41KW |
Capacity
Bloc sample |
Size |
Pieces/time |
Pieces/H |
Hollw block |
390*190*190mm |
10 |
2400 |
Multi-row perforated brick |
240*115*90mm |
24 |
5760 |
Standard block |
240*115*53mm |
48 |
11520 |
Pavment brick(single color) | 00*100*60mm | 0.72 m2 | 108 m2 |
Product Features
1. Vibrator and workbench become a whole so as to reduce processing of joint surface, fittings, the loss of energy transfer and improve the efficiency of the vibration, trepanning the workbench hole on the tank, and narrow trepanning area, put an end to the oil, to avoid damage to parts;At the same time increase the space between eccentric shaft holes, intermediate connection by excessive gear, thereby increasing the vibration effective area, making the vibration more homogeneous, ensuring compactness and strength of block products.
2. Using the air spring (gasbag pneumatic cylinder)clamping to realize optimal damping effect and the load measurement and height control.
Vibration isolation effect is good and can reduce the noise generated by mechanical vibration.
3. Quick mold changeover equipment, guarantee the clearance homogeneous between the upper pressure head and mold frame and mold replacement is quick and easy.
4. Using the displacement sensor (electronic ruler). The sensor can send message and control by displacement sensor.LEZ slide-block type mobile sensor (electronic ruler), with the durable conductive plastic resistor rail inside, is suitable for the applications of position measurement and automation control.
5. Increase the racks. A vibration table does not bear a mold and external load, and can reduce the number of vibration isolation spring, so that the vibration isolation system is more flexible and the noise will decrease accordingly.
Product Quality
Products produced at the production line must conform to the corresponding standards.
| Item | Hollow Brick | Multiple-hole Brick | Solid Brick | Colored Pavement Brick |
| Specification | 390*190*190mm | 240*115*90mm | 240*115*53mm | 200 * 100 * 60 mm |
| compressive strength | more than 10 Mpa | more than 15 Mpa | more than 15 Mpa | more than 30 Mpa |
Device Configuration
| concrete spreader | electronic batching station |
| ayer pallet mixer | automatic unloader machine |
| hydraulic system | secondary concrete spreader |
| part of host computer | automatic palletizing machine |
| loading machine | PLC electronic control system |
| cement silo | automatic discharging plate mixer |
Company Profile
Lingtong is a professional brick making machine manufacturer in china. and have passing the certifications of ISO9001 International Quality System, ISO14001 Environmental Management System and GB/T28001 Health and Safety System, and strictly enforces the ISO9001 Standards.
Lingtong continuously expands international market, and the products are exported to Central Asia, South America, Africa, Southeast Asia and the Middle East. In addition, Lingtong has set up an overseas customer service center in Russia, thus an internationalized Lingtong Heavy Industry is initially formed.
