Size:
From 20mm to 110mm
Connection:
Clamp
Type:
Angle
Material:
PP-R
Surface Treatment:
Galvanized
Customized:
Customized
Warranty:
12 Months
Application:
Building
Product Description
PP-R pipe has plastic pipe features such as light weight, corrosion resistance, no scale formation, long service life, but also has the following main features: 1, Non-toxic, health. The raw material moleculars of PP-R are only carbon, hydogen, they haven't toxic harmful elements, it's healty and reliability, it is used not only for the cold and hot water pipis, but also can be used for pure drinking water system. 2, Energy-saving insulation. Thermal conductivity of tube is 0.21w/mk PP-R, onle for the steel 1/200. 3, Good heat resistance. PP-R VEKA softing point is 131.5° C, the maximum operating temperture is up to 95° C, it can be used for the building hot water system 4, Long service life The service life of PP-P tube is up to 50 years in the working temperature 70° C, working pressure(P. N) under 1.0 MPa, the premise is the pipe must be above S3.2and S2.5 serives. It can be used more than 100 years in room temperature. 5, Convenient installation PP-R has godd welding performance, it can be heated and welded convenient easily, the joint strength is greater than the pipe itself. 6, The material Recyclable utilization. After cleaning, crushing and recyling, the PP-R can be reproduced pipes. If the recycled material is less than 10% of the total material, it doesn't affect the quality of the products.
Product Description PPR raw material: According your order Brss insert: 58# or 62# brass Main products: PPR fittings, PPR pipe, composite pipe, PPR ball valve, PPR stop valve, PPR filter, PPR union etc. Supply PPR fittings mould with very high quality Size: From 20mm to 110mm Working temperature: -40~ +95° C Pressure: 2.5Mpa Packing: With poly pag packing then in color carton OEM: Offer ISO9001, ISO14001 Standard: DIN8077/8078 Quality: 50years guarantee
PIC.
SIZE
ECONOMIC
Equal Tee
Bitmap
T20
T25
0.073
T32
0.127
T40
0.211
T50
0.392
T63
0.715
T75
1.177
T90
1.97
T110
3.425
T160
PPR Union
Bitmap
UN20
0.0736
UN25
0.1156
UN32
0.1577
UN40
0.2944
UN50
0.4206
UN63
0.757
UN20
0.101
UN25
0.143
UN32
0.2103
UN40
0.3575
UN50
0.5257
UN63
0.8832
Reducing Tee
Bitmap
TA25x20x25
0.07
TA32x20x32
0.091
TA32x25x32
0.103
TA40x20x40
0.171
TA40x25x40
0.183
TA40x32x40
0.19
TA50x20x50
0.245
TA50x25x50
0.276
TA50x32x50
0.312
TA50x40x50
0.352
TA63x20x63
0.355
TA63x25x63
0.463
TA63x32x63
0.502
TA63x40x63
0.612
TA63x50x63
0.624
TA75x32x75
0.697
TA75x40x75
0.805
TA75x50x75
0.887
TA75x63x75
1.037
TA90x40x90
1.142
TA90x50x90
1.308
TA90x63x90
1.595
TA90x75x90
1.699
TA110x50x110
2.008
TA110x63x110
2.439
TA110x75x110
2.674
TA110x90x110
2.909
TA160x110x160
Reduced Elbow
Bitmap
LA25× 20
0.052
LA32× 20
0.07
LA32× 25
0.082
LA40× 20
0.195
LA40× 25
0.258
LA40× 32
0.211
LA50× 40
0.281
LA63× 40
0.352
LA63× 50
0.469
High footed pipe clamp
Bitmap
HK20
0.026
HK25
0.03
HK32
0.033
HK40
0.042
HK50
0.049
HK63
0.056
Over Cross
Bitmap
∪ 20
0.112
∪ 25
0.175
∪ 32
0.298
Cross
Bitmap
C20
0.054
C25
0.087
C32
0.146
C40
0.235
c50
0.436
c63
0.596
Female threaded Elbow with disk
Bitmap
ZL20F1/2"
0.343
ZL25F1/2"
0.554
ZL25F3/4"
0.602
Felame threaded Tee
Bitmap
T20F1/2"
0.301
T25F1/2"
0.361
T25F3/4'
0.422
T32F1/2"
0.518
T32F3/4"
T32F1"
0.939
T40F1-1/4"
1.626
T50F1-1/2'
2.288
T63F2'
2.891
Female threaded Elbow
Bitmap
L20F1/2"
0.265
L25F1/2"
0.325
L25F3/4"
0.434
L25F1/2"
L32F3/4"
0.723
L32F1"
0.994
L40F1-1/4"
1.716
L50F1-1/2"
2.288
L63F2"
