North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Plastic Processed:
HDPE, PETG, PP, PE, PVC
Bottle Material:
PE, PP LDPE, HDPE, PVC
Working Type:
Extrusion Blowing
Bottle Volume:
100ml-60L
Working Station:
Single/Double Stations
Speed:
According to Bottle Size
Thickness Control:
Moog
Certificate:
CE, SGS, ISO
Installation:
by Our Engineers
Control System:
PLC Touch Screen Computer
Type:
Extrusion Blow Molding Machine
Raw Material:
PE
Making Method Of Parison:
Extrusion-Blow Molding
Automation:
Automatic
Computerized:
Computerized
Certification:
ISO9001:2008
Product Description
Full automatic plastic extruder blowing moulding machine For PE/PP, PVC
Functions:
Clamping system: Fixed two-way translation module structure Extruding system: Hard gear box + Delta inverter Die system: Storage die Hydraulic system: Yuken hydraulic valve / oil pump + electric hydraulic proportion control Circuit system: Mitsubishi PLC + man - and - computer interface + Temperature - controlled module
Max.Product Volume
(L)
60
Dry Cycle
(PC/h)
450
Screw Diameter
(mm)
90
Screw L/D ratio
(L/D)
25-30
Screw drive power
(KW)
45-55
Srew heating capacity
(KW)
20-25
Output of HDPE
(kg/h)
140-180
Oil pump drive power
(KW)
22-37
Clamping force
(KN)
240-300
Platen distance
(mm)
500-1000
Capacity
(L)
6.6
Max.Die diameter
(mm)
350
Die heat capacity
(kw)
9.5-11.5
The Average Consumption
(kw/h)
38
Blowing pressure
(Mpa)
0.8
Air volume
(M3/MIN)
1.0
Cooling water pressure
(Mpa)
0.3-0.4
Water consumption
(L/MIN)
100
Size of machine
(L*M*H)/m
4.6*2.5*4.0
Weight of machine
(TON)
14.5
