North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Including Shape:
Tube, Rod, Plate, Ring and So on
Practical Application:
Textile/Chemical/Electronics
Color:
White or Ivory
Refractoriness (',℃):
1580< Refractoriness< 1770
Feature:
Long Time Materials
Type:
Refractory Material
Shape:
Brick
Material:
Alumina Block
Product Description
Application Fine Ceramics In Practical Application Textile Industry Metal Working Wear Protection In Plant Engineering Chemical, Energy And Environmental Technologies Electrical Engineering And Electronics Ballistic Protection Automotive Technology Medical Industry
Our Equipment List
Produce Equipment
Quantity
Inspection Equipment
Dry Press Machine
5
Metalloscope
Cold Isostatic Pressing Machine
1
Digital display vickers hardness tester
Hot Press Machine
2
X-Ray Anlyzer
Tunnel Furnace
1
Optical Image Measuring Instrument
Atmosphere Furnace
1
Particle Size Analyzer
Metallization hydrogen sintering furnace
1
Measurement Tool such as Caliper,Digimatic Micrometer
Screen Print & Baking
1
Analytical Balance
Circular Tunnel Baking Line
1
Cooperated University Provided Equipment
Box Furnace
1
Process Equipment
Quantity
Max Precision(mm)
ZrO2 Best Roughness
Al2O3 Best Roughness
Min Key Size
Max Size
Surface Grinder
8
±0.002
Ra0.02
Ra0.2
T0.20*20*20
200*500
Milling Machine
4
Hole Dia±0.01
Ra1.6
Ra3.2
Hole Dia1*5(Deep)
Inside&Outside Cylindrical Grinder
3
OD±0.005
Ra0.01
Ra0.2
OD1*8(Lenth)
OD200*500
ID±0.005
Ra0.4
Ra0.8
ID5*8(Lenth)
ID100*200
Tool Grinder
1
OD±0.005
Ra0.01
Ra0.2
OD1*8(Lenth)
ID80*100
Inside Grinder
1
ID±0.005
Ra0.4
Ra0.8
ID3*5(Lenth)
ID80*100
Centerless Grinder
3
OD±0.001
Ra0.01
Ra0.2
OD0.7*60(Lenth)
Dia40*500
CNC Equipment
2
±0.02
Ra0.8
Ra1.6
650*650
Laser Process Machine
1
Size±0.02
Hole Dia0.10
1.5*200*200
Polishing Machine
1
T±0.02
Ra0.01
Ra0.2
T0.20*20*20
150*150
Lathe
1
Ra0.05
Ra0.2
Screw M3*6
Size and Precision is just for reference, it depends on the drawing or samples.
Equipment and produce capability can increase if necessary;
Produce precision also can improve with the technology developping.
Our Services Our Service: Customized components Precision Processing and polishing Recommended Material Mould & Tooling Design Engineering Testing Analysis Stable Quality Control Our Production manufacturing processing: Dry Pressing, Injection Iso-static Extrusion Hot Pressing Tape-casting
AIZA is a Lianyungang based Sino-Foreign joint venture corporation. It is a Chinese producer of calcined alumina and a manufacturer of alumina ceramics, such as alumina ceramic ball, alumina ceramic cylinder, alumina wear tile, ceramic insulator, ceramic element, ceramic beads, and other insulation ceramics with self-prepared material as well as German and Japanese material.
Since its creation, AIZA has served most of Chinese customers, Nanjing Huade, Zhuzhou Xianghuoju, and Chaozhou Sanhuan, which are eminent manufacturer of spark plug and advanced ceramic in China. Its "TCH" brand calcined alumina is well accepted by our customers.
In 2008, AIZA purchased 70 key equipment from Shanghai Morgan Matroc after its closure in China. The equipment includes isostatic press machine, dry press machine, hot press cast machine, ball mill, alumina spray prilling tower (centrifugal and pressure), polishing machine, etc. The equipment has been successfully installed in our factory by the end of 2008. Now, AIZA have succeeded in establishing itself as sole Chinese manufacturer of ceramic nozzle by isostatic dry bag pressing process. Besides, the most experienced technical engineer of former Shanghai Morgan Matroc also joined us, which is the precious source of our confidence of ensuring products quality.
TQC Procedures and ISO 9001: 2000- Certification
Our experienced QC will supervise the production and check the quality before delivery. We conduct TQC procedures according to ISO 9001: 2000-certified guidelines. In order to ensure better quality, we carry out five processes below:
1. Material inspection
2. Semi-manufactured goods inspection
3. Itinerary inspection
4. Finished products inspection
5. Shipment inspection.
Material Adopted:
Alumina
Zirconia
Steatite
Alumina-Zirconia
AIZA is a Lianyungang based Sino-Foreign joint venture corporation. It is a Chinese producer of calcined alumina and a manufacturer of alumina ceramics, such as alumina ceramic ball, alumina ceramic cylinder, alumina wear tile, ceramic insulator, ceramic element, ceramic beads, and other insulation ceramics with self-prepared material as well as German and Japanese material.
Since its creation, AIZA has served most of Chinese customers, Nanjing Huade, Zhuzhou Xianghuoju, and Chaozhou Sanhuan, which are eminent manufacturer of spark plug and advanced ceramic in China. Its "TCH" brand calcined alumina is well accepted by our customers.
In 2008, AIZA purchased 70 key equipment from Shanghai Morgan Matroc after its closure in China. The equipment includes isostatic press machine, dry press machine, hot press cast machine, ball mill, alumina spray prilling tower (centrifugal and pressure), polishing machine, etc. The equipment has been successfully installed in our factory by the end of 2008. Now, AIZA have succeeded in establishing itself as sole Chinese manufacturer of ceramic nozzle by isostatic dry bag pressing process. Besides, the most experienced technical engineer of former Shanghai Morgan Matroc also joined us, which is the precious source of our confidence of ensuring products quality.
TQC Procedures and ISO 9001: 2000- Certification
Our experienced QC will supervise the production and check the quality before delivery. We conduct TQC procedures according to ISO 9001: 2000-certified guidelines. In order to ensure better quality, we carry out five processes below:
1. Material inspection
2. Semi-manufactured goods inspection
3. Itinerary inspection
4. Finished products inspection
5. Shipment inspection.
Material Adopted:
Alumina
Zirconia
Steatite
Alumina-Zirconia
