Prod Model: |
RCG-500 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Working Table Size: |
600 X 500mm |
Work Stroke: |
500 X 400 X 120mm |
Servo Motor: |
Japan AC Servo Motor |
Spindle Power Rate: |
1.5/2.2kw (Optional) |
Movement Method: |
Linear Control |
Control Method: |
Closed-Loop Control |
Numerical Control: |
CNC/MNC |
Performance Classification: |
Economical CNC Machine Tools |
Process Usage: |
Glass Engraving CNC Machine |
Processing Precision: |
0.01mm |
Product Description
Specifications/Special Features:
Control system: Shanghai WeiHong
Working table size: 600 x 500mm
Work stroke: 500 x 400 x 120mm
Servo motor: Japan AC servo motor
Frequency transformer: 2.2kW
Spindle power rate: 1.5/2.2kW (optional)
Spindle rotational: 240000rpm
Tools type: ER20
Tool capacity: Ø 1 to 10mm
Working table loading: 100kg
Position accuracy: 0.01mm
Repositioning: 0.005mm
Maximum travel speed: 9m/min
Maximum cutting speed: 6m/min
Power supply: AC 220V/3kW
Lathe bed size: 1350 x 1150 x 1750mm
Machine net weight: 1200kg
Features:
Integrally cast lathe bed, robust, and durable, with auto hand wheel, easy to operate
Iron cast lathe frame, low noise, high precision, stable movement
Servo motor and max travel speed: 9m/min, engraving speed: 6 m/min
Taiwan HIWIN liner guider, low noise, strong cutting strength, and ensuring long time mass processing
Applications:
Suitable for PCB fixture, glass, small size mold, parts, copper electrode machining
Optional:
Spindle cooling system
Electronics hand wheel
Lock nozzle
High speed spindle
Oil cooled chiller
Work light
Automatic waste recycling plant
Automatic lubricator
