North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Sales Market:
20 More Than Countries
Warranty:
1 Year
Control Way:
Automatic PLC System
Structure Mode:
Four Column, Frame Type
Type:
General Rubber Machinery
Type Of General Rubber Machinery:
Material Processing Machine
Type Of Tire Machinery:
Rubber Regeneration Machinery
Certification:
CE, ISO
Product Description
Applicable for vulcanizing all kinds of rubber and plastic model and non-model products
1. High speed open/close mold, stable pressure, good control in vulcanizing time and temperature.
2. Automatic and manual operation system, design by your order.
3. Stabile performance, good quality and reliable service.
4. The right of import and export, Supply promptly quickly.
Our company is a professional production of rubber machinery company, has the independent production companies and import and export corporation. The company has the abundant technical force and rich production experience. Our main products: Plate vulcanizer, open mixing mill, mixer, tire vulcanizing machine, rubber cutting machine, rubber extrusion machine, rubber tile vulcanizing press, tyre crusher etc. Complete sets of equipment are: Ordinary conveyor belt production line, waste tyre reclaimed rubber powder production line. We can also according to the customers request; Design and manufacture all kinds of standard rubber machinery and equipment.
My company's products have passed the certification of the various, such as: Plate vulcanizing machine has passed the SGS certification, scrap tire rubber powder production equipment certified by BV certification (France). Product best-selling more than 30 provinces and regions, and exported to southeast Asia, the Middle East, Africa, Europe and the America and other 20 shelves and regions.
Type
XLB-DQ1200×1200×2
XLB-DQ1300×2000×1
XLB-Q1200×2500×1
XLB-Q1500×2000×1
XLB-Q2000×3000×1
XLB-Q1400×5700×1
Total pressure(MN)
315t
560t
750t
1000t
1800t
2800t
Plate size(mm)
1200×1200
1300×2000
1200×2500
1500×2500
2000×3000
1400×5700
Daylight(mm)
200
400
400
400
400
400
Layer
2
1
1
1
1
1
Piston stroke(mm)
400
400
400
400
400
400
Plate unit area pressure (kg/ cm2)
22
21.5
25
33.5
30
35
Main motor power(KW)
3
8
9.5
11
26
43.5
Overall dimension (L×W×H)(mm)
1685×1320×2450
2000×1860×2500
2560×1700×2780
2810×1550×3325
2900×3200×2860
2400×5800×3600
Weight (kg)
9500
17000
20000
24000
66000
110000
Type
XLB-DQ400*400*2
XLB-DQ600*600*2
XLB-DQ750*850*2
XLB-DQ1000*1000*2
XLB-DQ1500*1500*2
XLB-DQ300*300*2
Total pressure
0.50 MN
1.00 MN
1.60 MN
4.00 MN
8.00 MN
0.25 MN
Plate size
400*400 mm
600*600 mm
750*850 mm
1000*1000 mm
1500*1500 mm
300*300 mm
Plate clearance
125 mm
125 mm
125 mm
125 mm
125 mm
125 mm
Working layer nuber
2
2
2(4)
2(4)
2(4)
2
Piston stroke
250 mm
250 mm
250(500)
250(500)
250(500)
250 mm
Plate pressure
3.1 Mpa
2.8 Mpa
2.5 Mpa
4.0 Mpa
3.6 Mpa
2.1 Mpa
Motor power
2.2 kw
3 kw
3 kw
5.5 kw
5.5 kw
2.2 kw
weight
1300 kg
3500 kg
6500 kg
11000 kg
22000 kg
1050 kg
Qingdao Eenor SCIENCE&TECHNOLOGY Co., Ltd is a professional production of rubber machinery company, has the independent production companies and import and export corporation. The company has the abundant technical force and rich production experience. Our main products: Plate vulcanizer, open mixing mill, mixer, tire vulcanizing machine, rubber cutting machine, rubber extrusion machine, rubber tile vulcanizing press, tyre crusher etc. Complete sets of equipment are: Ordinary conveyor belt production line, waste tyre reclaimed rubber powder production line. We can also according to the customers request; Design and manufacture all kinds of standard rubber machinery and equipment.
My company's products have passed the certification of the various, such as: Plate vulcanizing machine has passed the SGS certification, scrap tire rubber powder production equipment certified by BV certification (France). Product best-selling more than 30 provinces and regions, and exported to southeast Asia, the Middle East, Africa, Europe and the America and other 20 shelves and regions.
Our Company Motto: "THE HONESTRY IS THE ROOT, A PROMISE IS A PROMISE" the enterprise idea, adhere to market-oriented, providing customers with advanced products and quality services. Mr kIMSUN PANG(Chairman) together with all staff warmly welcome customers at home and abroad to the company to negotiate, guidance, my company is willing to first-class technology, first-class service, first-class quality, sincerely service for you.
Qingdao Eenor SCIENCE&TECHNOLOGY Co., Ltd is a professional production of rubber machinery company, has the independent production companies and import and export corporation. The company has the abundant technical force and rich production experience. Our main products: Plate vulcanizer, open mixing mill, mixer, tire vulcanizing machine, rubber cutting machine, rubber extrusion machine, rubber tile vulcanizing press, tyre crusher etc. Complete sets of equipment are: Ordinary conveyor belt production line, waste tyre reclaimed rubber powder production line. We can also according to the customers request; Design and manufacture all kinds of standard rubber machinery and equipment.
My company's products have passed the certification of the various, such as: Plate vulcanizing machine has passed the SGS certification, scrap tire rubber powder production equipment certified by BV certification (France). Product best-selling more than 30 provinces and regions, and exported to southeast Asia, the Middle East, Africa, Europe and the America and other 20 shelves and regions.
Our Company Motto: "THE HONESTRY IS THE ROOT, A PROMISE IS A PROMISE" the enterprise idea, adhere to market-oriented, providing customers with advanced products and quality services. Mr kIMSUN PANG(Chairman) together with all staff warmly welcome customers at home and abroad to the company to negotiate, guidance, my company is willing to first-class technology, first-class service, first-class quality, sincerely service for you.
