| Markets: | South America,Southeast Asia,Africa,Mid East |
|---|---|
| Automatic: | Yes |
| Computerized: | Yes |
| Making Method Of Parison: | Extrusion-Blow Molding |
| Type (',For Injection Machine): | Full-Electric Controlled |
| Kind: | Full-Electric Controlled |
| Processing Technics: | Blow Molding Machine |
| System | Item | Unit | Basic parameter |
|
Basic Spec |
Plastic fit for | PE PP PVC PA… | |
| Max hollow product volume | L | 2.5 | |
| Diehead amount | set | upon to 6 dieheads for option | |
| Size(LxWxH) | M | 3.23x2.184x2.28 | |
| Weight | ton | 3.4 | |
|
Clamping System |
Clamping force | kN | 30 |
| Template distance | mm | 120-350 | |
| Template stroke | 230 | ||
| Max template size(WxH) | mm | 340x320 | |
| Mould thickness | mm | 125-220 | |
|
Extrusion System |
Screw Dia | mm | 60 |
| Screw L/D ratio | L/D | 23 | |
| Plasticizing capacity (HDPE) | Kg/h | 60 | |
| Screw heating zone | zone | 3 | |
| Screw heating power | kW | 9 | |
| Screw fan’s power | kW | 0.42 | |
| Extrusion motor’s power | kW | 15 | |
|
Die head |
Diehead heating zone | zone | 2 |
| Diehead heating power | kW | 4.2 | |
| Sprue-die dia(max) | mm | 75 | |
|
Power |
General power | kW | 34.5 |
| Oil-pump motor power | kW | 5.5 | |
| Air pressure | Mpa | 0.6-0.8 | |
| Average power | kW | 23 | |
| Compressed air dosage | m 3 min | 0.4 | |
| Cooling water dosage | L/min | 40-50 | |
