Pump(oil)overload protection to effectively ensure service life.
Alarm device for low liquid level to guarantee system running safety.
Swithch of main power source conforms to CE safety standard.
Phase reverse equipment to guarantee system running safety.
The machine is equipped converse alarm function Multi fault indicator lamp to facilitate the ustomer knowing the reason and handling in time.
The heating barrel is made from the stainless steel and cleaned easily.
Air blowing can be selected for the mould to ensure temporarily clean placing and prolong the service life.
Specifications
Model
Max temp.°C
Heat Kw
Pump Kw
Flkux L/min
Pressure Bar
Heating Medium
Cooling Mode
Mold Tie Lnch
Exteral Dimensions
Weight(kg)
JCTC-6W
95
6
0.37
45
3
Water
Direct Cooling
3/8"2*2
900*350*700
65
JCTC-9W
95
9
0.75
56
4
3/8"4*2
900*350*700
68
JCTC-12W
95
12
1.5
80
5.5
3/8"6*2
900*350*700
70
JCTC-24W
95
24
2.2
315
4
3/8"8*2
900*350*700
100
JCTC-6W-2D
95
6*2
0.37*2
45*2
3
3/8"2*2
900*600*700
110
JCTC-9W-2D
95
9*2
0.75*2
56*2
3
3/8"4*2
900*600*700
115
JCTH-9W
160
9
0.75
165
3
Water
Indirect Cooling
3/8"4*2
900*350*700
90
JCTH-12W
160
12
1.5
235
3.5
3/8"4*2
900*350*700
115
JCTH-24W
160
24
2.2
315
4
3/8"4*2
900*350*700
130
What is Specifications of mould temperature controller? Size: according to clients' requirement Buyer's logos and designs acceptable. Our Extrusion blow molding machine and other blow molding machine can promise high quality of bottle and enjoy your big quantity requirement.
