Guarantee:
1year
Function:
Hot Water Boiler
Usage:
Industrial
Pressure:
High Pressure
Burning Style:
Chamber Combustion Boiler
Drum Placement:
Horizontal Boiler
Media:
Hot Water
Installation:
Packaged Boiler
Water Circulation:
Natural Circulation
Manufacturing Level:
B
Fuel:
Gas/Oil Fired
Structure:
Water and Fire Tube
Product Description
WNS Fuel type: Diesel oil, heavy oil, natural gas, city gas Boiler character: Use ripple furnace and screw thread smoke tube, high heat efficiency; Horizontal three-pass and wet back structure; Automatic control system Remark: The burner brand is according to the order of user
WNS0.7-0.7 -95-70-Y(Q)
WNS1.4-0.7 -95-70-Y(Q)
WNS2.1-0.7 -95-70-Y(Q)
WNS2.8-0.7 -95-70-Y(Q)
WNS3.5-0.7 -95-70
WNS4.2-0.7 -115-70
WNS5.6-0.7 -115-70
WNS7.0-0.7 -115-70
(MW) thermal power
0.7
1.4
2.1
2.8
3.5
4.2
5.6
7.0
(Mpa) Working pressure
0.7
0.7
0.7
0.7
1.0
1.0
1.0
1.0
(C) Outlet water temperature
95
95
95
95
95
115
115
115
(C) return water temperature
70
70
70
70
70
70
70
70
(t/h) Quantily of circulating water
24
48
72
96
120
80
107
133
(%) Efficiency
92.48
92.08
90.08
91.04
91.4
91.1
91.4
90
Fuels suitable
\\\ Light oil,Heavy oil,Natural gas,Liquefied gas
(kg/h) the boiler full load Light oil consumption
61.95
128.6
192.68
257.8
327
39
524
658
(Nm³/h) the boiler full load Natural gas consumption
71.5
148.3
223.1
297.6
374.4
450.5
601.5
754.8
(kJ/h) the boiler full load Heavy oil consumption
66.8
137.5
207.1
275.6
343.9
41.3
554.4
692.7
Large transport size
3.18×1.37×1.89
3.97×1.50×2.17
4.76×2.59×2.64
5.12×2.68×2.88
5.66×2.41×3.17
6.3×2.56×3.17
6.94×2.62×3.32
7.0×2.76×3.48
Max transport weight
3.33
4.838
6.849
8.9
15.6
17.8
21.2
26.4
Applicable altitude
1000
LD. Of supply water
DN80
DN100
DN125
DN125
DN125
DN150
DN150
DN150
LD. Of outlet water
DN80
DN100
DN125
DN125
DN125
DN150
DN150
DN150
LD. Of safety valve
DN40
DN40
DN50
DN50
DN80
DN80
DN100
DN100
LD. Of blow down pipe
DN40
DN40
DN40
DN40
DN50
DN50
DN50
DN50
chimney diameter
350
350
450
450
500
500
700
700
