Raw Materials:
PE Granules
Diameter:
Max. 50mm
Size:
According to Customer's Request
Other Equipments:
Crusher, Pulverizer, Chiller
Type Of Pipe:
Single Wall
Industrial Voltage:
Depends
Iron Steel In The Pipe:
with
Moulding Block For Both Diameter:
20&25, 16&32
Material Treatment:
Vacuum Loader and Hopper Dryer
Forming Blocks:
with
Certification:
ISO9001:2008
Automation:
Automatic
Computerized:
Non-Computerized
Product Type:
EVA,PE Pipe
Product Description
PE single wall corrugated pipe extrusion line
1. PE single wall corrugated pipe extrusion line mainly includes: Extruder, mould, calibration tank, haul-off, cutter, winder. 2. PE single wall corrugated pipe has the features of light weight, high corrosion resistance, erosion resistance and cold and hot resistance. 3. corrugated pipes are widely used in such field of communicatins, electric wire&cable laying and agricultural irrigation, etc. 4. Optional equipments: Winder, crusher, etc
Brief technical parameters
Model
LGP-C25
LGP-C50
LGP-C75
LGP-C160
Screw diameter
50mm
63mm
65mm
75mm
Diameter of pipe
16-25mm
16-50mm
50-75mm
90-160mm
Speed
15m/min
10m/min
10m/min
5m/min
L/D
30: 1
30: 1
33: 1
33: 1
Total power
50kw
70kw
80kw
100kw
Zhangjiagang Longree Technology Co., Ltd. is one of the famous manufacturers of plastic mixing, extrusion, surface decoration and recycling machine.
Longree Technology is located in Zhangjiagang, Jiangsu Province, close to the international metropolis Shanghai, only 120km away from the Shanghai Pudong International Airport.
In our Longree group, there are plastic conveying-mixing, extrusion, surface decoration, recycling equipment manufacturing plants, crusher and pulverizer plant, professional screw manufacturing plant, screw gearbox manufacturing plant and a PC products plant( in Russia).
We can supply wide range of all kinds of plastic machinery. We have a strong technical team, experienced workers, and a professional after-sales team. All of these ensure our super quality, competitive price and satisfying after-sales service.
We continue to improve equipment performance based on customers' feedback. Now the Customer Satisfaction Rate is about 98%. Growing up together with the customers, with this development concept, Longree`s products not only have a big market in China, but also exported to: Moscow (Russia), Istanbul (Turkey), Dubai (UAE), Helsinki (Finland), Buenos Aires (Argentina), Brazil, (Cairo)Egypt, India and other countries and regions.
Our main products are as follows:
1 Extruder
2 Pipe production line
3 Profile production line
4 Sheet production line
5 Board production line
6 WPC production line
7 Granulation line
8 Recycling line
9 Mixer
10 Auxiliary machine
