Product:
Metallizing Vacuum Coating Machine
Business Type:
China Manufacturer/Supplier
Model:
Lh-Series
Certification:
ISO90001
Coating Technology:
Ion Coating
Structure:
Vertical, Single Door
Control System:
Automatic Manual All-in-One
Operating System:
PLC Touching Screen
Coating Color:
Gold, Resegold, Silver, Black, Blue, Rainbow Ect
Chamber Material:
Stainless Steel
Coating:
Vacuum Coating
Type:
Coating Production Line
Substrate:
Metal/Steel
Product Description
Porcelains tiles Metallizing Vacuum Coating Machine (suitable for glass,ceramic,metal,mosaic,crystal ect)
Specifications
Porcelain tiles metalizing vacuum coating machine 1. Extend workpiece service life. 2. Improve the workpiece hardness
Porcelains tiles metalizing vacuum coating machine is a ion coating machine of efficiency, harmless and pollution-free. It has the features of fast deposition rate, great ionization rate, big ion energy, easy operation, low cost, large productive capacity, etc.
Characteristic: The principle of the electric arc is intergrating cold cathode arc discharge self-sustained light unite pulse technique and magnetron sputtering technology, thinning the particles to improve the properties of the film. It can coat on the surface of the metal as well as nonmetal.
Applied industry: It can be used to coat metal film, titanium nitride, titanium carbide, and Zirconium nitride, chromium nitride and titanium, nickel, chromium, copper, and other compounds film, multi-layer super-hard film, nitrogen-doped titanium film and the alloy film, and in a very short time to complete all the machining process, it is a highly efficient multi-functional coating equipment
Porcelains tiles metalizing vacuum coating machine is extensively used in the fields of ultra-hard coating about the tools and mould, decorative coating about car wheels, ceramics, golf, watches making, hotel product, sanitary ware, luminaires, optical frame, hardware, etc.
This is our machine: Samples coated by our machine:
Mode
Dimension
LH-800
LH-1000
LH-1250
800*1000mm
1000*1000mm
1250*1500mm
Coating mode and main confirguration
Eight multi-arc targets
Ten multi-arc targets
Twelve multi-arc targets
Power source
Electric-arc power, Filament power,
Process gas control
Mass flowmeter + Electromagnetic ceramic valve
Vacuum chamber structure
Vertical side opening door, pump system postposition, double water cooling
Normal temperature to 350 centi-degree PID control, radiation heating.
Workpiece motion mode
Public rotation Frequency control: 0-20 rotation per minute
Measure mode
Number display composite vacuum gauge: from atmosphere to 1.0*10 -5 Pa
Control mode
Manual/Automatic/PC/PLC + HMI/PC four choice of control mode
Remark
We can design the dimension of the equipment according to customers special technique requirement.
