Company:
More Than 10years Experience
Use:
Production Rubber Products
Plunger:
Chilled Alloy Cast Iron
Heating:
Electric, Steam
Press:
Hydraulic
Pedestal:
Cast Iron, Section Steel H
Type:
General Rubber Machinery
Type Of General Rubber Machinery:
Material Processing Machine
Type Of Tire Machinery:
Rubber Curing Press
Weight:
<50 tons
Certification:
CE, ISO, SGS
Product Description
Rubber Forming Machine / Vulcanizing Machine
Also named Rubber molding press; Hydraulic Molding Machine; Hydraulic press; Plate press, compression press; Plate vulcanizing machine, vulcanizer.
Main usage 1, The frame type plate vulcanizer applies to vulcanize all kinds of rubber and plastic mould products as well as non-mould products. 2, Applicable line: Rubber Sheet, Oil Seal, O Ring, Gasket, Engine Mountings, Hardware Rubber, Molded Rubber Parts and etc.
Characteristic 1. This vulcanizing machine is used for all kinds of vulcanizing mould, rubber and plastic mould products, and non-mould products. 2. The machine is in frame structure with below pressing form (upwards). Under the working hydraulic pressure, the embolism ascends To make hot plate close for getting pressure, while the embolism descends (namely hot plate turning on) by deadweight of hot plate, Platform and embolism to drive working fluid to fuel reserve tank to achieve the aim of descending (namely turning on). 3. Made of nodular cast iron, the oil cylinder of machine is improved in compressive strength and wear resistance. Seal ring made of oil-proof rubber is placed in oil cylinder to have sealing effect in working process of this machine. Combined oil pump, power source of the machine, provides working fluid with certain pressure. Working fluid enters into oil cylinder By control valve to make control handle on control valve turn to different places, and then embolism is able to ascend or descend. 4. Adopting tubular electric-heating component to heat up, the machine can reduce air pollution to keep workshop clean without boiler. 5. The machine is beautiful in shape, rational in structure, convenient in control, safe and credible as well.
Main parameters/Model
XLB--D/Q300x300x2
XLB--D/Q350x350x2
XLB--D/Q400x400x2
XLB--D/Q600x600x2
Nominal and mould force
0.25
0.25
0.5
1
Specification of hot plate
300x300
350x350
400X400
600X600
Number of working layer
2
2
2
2
Piston diameter
140
140
200
300
Max stroke of piston
250
250
250
250
Distance between hot plate
125
125
125
125
Unit area pressure of hot plate
3.5
2.04
3.1
2.78
Motor power
2.2
2.2
2.2
2.2
weight
1000
1000
1500
2700
Overall size
1200*580*1200
1200*580*1200
1780*600*1300
20470*810*1600
comment:we kan be individually customized according to customer requirements.
