1. The all steel welds the structure, vibration dispels the stress, the machine is good in intensity, rigidity is good.
2. Having the transmission in hydraulic pressure, it is reliable to be steady.
3. Machinery blocks one, sprain the axle and move ahead simultaneously, the precision is high.
4. It and then can't block material from, last pieces of journey not slippery not regulating electronically, the manual to finely tune, digital display.
5. Have mould furnished with deflection compensate structure, more than 250 tons is it down mould's deflection compensate the structure to adopt.
name / specification
Nominal pressure KN
Length mm of the workingbench
Slippery journeys mm
Regulating amount mm of slippery journeys
Number of times of the journey 1 / min
Net weight kg
Power kw of the main electrical machinery
External dimension mm
40/2000
400
2000
100
80
11
2600
3
2085*1270*1800
50/3200
500
3200
100
80
11
3500
3
3285*1500*2300
63/2500
630
2500
100
80
10
4500
5.5
2560*1730*2300
63/3200
630
3200
100
80
10
5500
5.5
3260*1730*2360
80/3200
800
3200
100
75
8
6500
7.5
3280*1800*2400
80/4000
800
4000
100
75
8
7500
7.5
4080*1820*2400
100/3200
1000
3200
120
100
8
8200
7.5
3280*1820*2430
100/4000
1000
4000
120
100
8
1000
7.5
4080*1820*2430
125/3200
1250
3200
120
100
8
8700
7.5
3280*1820*2430
125/4000
1250
4000
120
100
8
10600
7.5
4080*1820*2430
160/3200
1600
3200
200
160
8
10500
11
3280*1940*2660
200/3200
2000
3200
200
160
7
14500
15
3280*2040*3020
200/4000
2000
4000
200
160
7
17500
15
4080*2040*3450
300/5000
3000
5000
250
160
≥3
29
15
5100*2600*3400
400/6000
4000
6000
320
200
≥2.5
39.5
30
6100*2650*3900
500/6000
5000
6000
320
250
≥2.5
59
37
