Sole Machine:
Injection Molding
Injection Molding Machine:
Machine
Sole Injection Machine:
Injection Moulding Machine
Shaping Mode:
Injection Mould
Process Combination Type:
Single-Process Mode
Application:
Home Use
Installation:
Mobile
Product Description
Mpplicable scope:
Bicolor sole, injection, bicolor plastic injection Applicable material: TR, TPU, TPR, PVC, and so on
Main Feature 1. Siemens PLC control system allows the machine z stablework.
2. Schneider Electric parts ensure the electric controlsystem of the machine stable and reliable.
3. Dofluid hydraulic valve ensure the oil circuit smoothand stable.
4. Crane connecting bar die molding allows stable mold clamping force.
5. Rapping bar turn over automatically, counterdie shifts out to ensureeasiness, convenience, and quickness of taking out the products, moldinserting.
6. Push-out automatically and no product detormation in ensured, fully reducingthe work intensity of the operator.
7. Open touch panel allows a at any time control on operating condition and adiagnosis of abnormal condition.
8. Template and mold are cooled by water, which increase the output.
9. Lubricate automatically to make up the shortage of manual maintenance and tolengthen the life time of the machine.
10. The machine has four safety devices, operated by machine, electricity,water and air, which ensure the operation safe.
11. Servo motor sharply saves power energy 50%consumption .
ltem
Unit
HC-T0204-A
number of Station
Statian
2
Clamping
Ton
220
Mould Dimensions
mm
300x400
Max.Opening stroke OF the Mold
mm
350
Argles of Rotating head
0°-90°
Screw Diameter
mm
65
Screw speed
rpm
0-185
Thermal zone of barrel
No.
3+1
Injection pressure
mpa
95
Injection volume
Cm3
860
Length-diameter ratio L/D
L/D
22
Extrusion unit
Kw
13
Max.electric consumption
Kw
46
The average power consumption
Kw
30
Measurement L*W*H
Mm
2300x3200x2500
Weight approximate
ton
11.5
Established in 2002, Ningbo Haicer Machinery Co., Ltd. is a company specializing in the design and production of sole machines and shoe factory equipment. After years of practice and with client suggestions, the company continues to improve its products gradually, so that the Haicer products enter the international market gradually: Currently Haicer products are sold all over the world: India, Vietnam, Bangladesh, Argentina, Colombia, Bolivia, Brazil, Spain, Peru, Ukraine, and other countries.
Haicer Machinery Co., Ltd. is located in the port city of Ningbo, which has beautiful environment, convenient transportation and fast shipping, making it a good base for the production of machinery and equipment. In addition, Haicer has strong production capacity, a full range of processing equipment, and perfect professional detection system, which fully guarantee the quality of Haicer machinery products and customers' interests.
Integrity is the unchanged objective of Haicer Machinery Co., Ltd. For years, honest is the criteria of Haicer, and efforts for customer service are the primary responsibility of Haicer. Haicer is your right choice, and welcome to visit our company.
Established in 2002, Ningbo Haicer Machinery Co., Ltd. is a company specializing in the design and production of sole machines and shoe factory equipment. After years of practice and with client suggestions, the company continues to improve its products gradually, so that the Haicer products enter the international market gradually: Currently Haicer products are sold all over the world: India, Vietnam, Bangladesh, Argentina, Colombia, Bolivia, Brazil, Spain, Peru, Ukraine, and other countries.
Haicer Machinery Co., Ltd. is located in the port city of Ningbo, which has beautiful environment, convenient transportation and fast shipping, making it a good base for the production of machinery and equipment. In addition, Haicer has strong production capacity, a full range of processing equipment, and perfect professional detection system, which fully guarantee the quality of Haicer machinery products and customers' interests.
Integrity is the unchanged objective of Haicer Machinery Co., Ltd. For years, honest is the criteria of Haicer, and efforts for customer service are the primary responsibility of Haicer. Haicer is your right choice, and welcome to visit our company.
