Color:
Can Be Customized
Delivery Detail:
3-30 Days After Receipt
Brand:
Annov or as Customer's Request
Max Thickness Of Coiled Plate:
25 Mm
Max Width Of Coiled Plate:
2000 Mm
Yield Limit Of Sheet Metal:
245 Mpa
Coiling Speed:
4 M/Min
Diameter Of Bottom Roll:
320 Mm
Diameter Of Side Roll:
280 Mm
Max Stroke Of Side Roll:
280 Mm
Forging Forming Method:
Mold Forging
Product Description
End pre-bending of high precision High Accurate End Pre-bending when bending the end, it can freely set the length of the edge. Top roller presses down, and high accurate end pre-bending is done under a certain pressure. Technical parameters for small-size & medium-size top roll universal plate rolling machine
Different uses with coordinating controlling methods Three are following controlling methods according to its use. TNC ( Top NC ): For many types but small quantity of production; T&BNC (Top and Bottom NC ): For few types but large quantity of production; CNC ( CNC ): For many types but large quantity of production.
Excellent product precision Products Have Superior precision Due to continuous bending and high Accurate end pre-bending, products have superior precision. As the top roller Is in the shape of drum, with the supporting roller adjusted, it can coil ideal Products in the wide range from sheets to plates.
CNC control high producing efficiency CNC Controls High Production Efficiency One operator, simple operation, and High efficiency.
Rich bending shapes There are such different shapes as O shape, U shapes and multi-section Shapes. The method is as follows: O bending: Back bending mode U bending: Front bending mode Special bending: Composition mode
Technical parameters for small-size&medium-size top roll universal plate rolling machine
Model
Pressure on the top roll
Max plate thickness
Plate width
Diameter of top roll
Diamter of down roll
Central distance
Motor
end bending
central
Driving
Hydraulic
Shift
Tons
mm
mm
mm
mm
mm
mm
Kw
Kw
Kw
W11S-55x3000
610
45
55
3000
620
360
650
75
30
15
W11S-60x3000
690
50
60
3000
650
380
700
75
30
15
W11S-50x4000
690
45
50
4000
700
380
700
75
30
15
W11S-70x3000
850
60
70
3000
710
420
780
75
37
15
W11S-55x4000
850
50
55
4000
750
420
780
90
37
15
W11S-50x5000
850
42
50
5000
790
420
780
90
37
15
W11S-45x6000
850
38
45
6000
820
420
780
90
37
15
W11S-75x3000
930
65
75
3000
740
440
820
90
37
15
W11S-60x4000
930
55
60
4000
780
440
820
90
37
15
W11S-55x5000
930
45
55
5000
820
440
820
90
37
18.5
W11S-80x3000
1050
70
80
3000
770
460
880
90
37
18.5
W11S-65x4000
1050
60
65
4000
810
460
880
90
37
18.5
W11S-85x3000
1150
75
85
3000
800
480
920
110
37
18.5
W11S-70x4000
1150
65
70
4000
840
480
920
110
45
18.5
W11S-100x3000
1350
90
100
3000
860
520
1000
110
45
22
W11S-80x4000
1350
75
80
4000
900
520
1000
110
45
22
W11S-65x6000
1350
60
65
6000
980
520
1000
110
45
22
W11S-115x3000
1600
100
115
3000
900
560
1080
132
55
30
W11S-100x4000
1600
85
100
4000
940
560
1080
132
55
30
W11S-125x3000
1800
110
125
3000
960
600
1120
160
75
37
W11STNC-45X3000-W11STNC-110X4000
ibidem
