North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe
Automatic Grade:
Automatic
Machine Size L*W*H:
4.2m*1.2m*1.8m
After-Sales Service Provided:
Engineers
Place Of Origin:
Shanghai
Speed:
120m/Min
Product Description
UNGAR CO., LTD. is an Austrian company in Shanghai China specializes in:
-aluminium foil rewinding machine
-aluminium foil container machine
-aluminium foil container mould
Product Description
Multifunction rewinding machine developed against foreign equipments and domestic requirements, which is a fully automatic machine to adhering, take-up, cutting certain rolls in one process .It is suitable for various large jumbo roll into small and narrow roll, such as household aluminum foil roll, paper roll, plastic roll, etc...
Model
UNRW-4212
Machine Size L x W x H
4.2m*1.2m*1.8m
Thickness of Material
0.008mm - 0.03mm
Width of Material
200 - 600mm
Inner Core Diameter of Finished Roll
90mm
Roll Cutting Size
3 - 500m
Voltage
380V 50HZ
Speed
120m/min
Power
4kw
Pneumatic
0.5-0.8Mpa
Station
4 Station
Weight
1800kg
Advantages: 1. Computer control to setup and measure the length of foils. 2. High process rate for large volume production. 3. All drivers are automatic, less defect, safety, high efficiency and simple operating.
Application: Auminium foil roll, paper roll, plastic roll, etc...
UNGAR (Shanghai) Co., Ltd is an Austrian enterprise established in 2009 supplying high productive multi-cavity mould and machinery which includes press, stacker, package, re-winder, paper lid cutting, decoiler, scrap aspirator and additional equipments. UNGAR complete integrated production line has been specially designed and developed for the production of aluminum food container and trays.
UNGAR (Shanghai) Co., Ltd as a technology leader focusing on researching and developing new products with a professional design team, technical department and sales group. In this way, the design team with its headquarter in Austria, manufacturing factory located in Shanghai, professional engineers service and global sales linking by Europe, America, Middle East Gul-food area and most of Asian countries.
UNGAR (Shanghai) Co., Ltd also offer customized service for technical optimization, mould prove, machine installation, material test, training course, telephone assistance and so on. UNGAR more than just a manufacturer...
UNGAR success can be attributed to the cohesive team environment, both at a state and international level; By drawing from each states market experience, group buying capabilities and deep knowledge pool, UNGAR dynamic team has cemented their company's position as market leader.
Management Team
UNGAR team of long standing managers provide guidance and direction, drawing from their solid experience and industry knowledge, ensure the company's strategic direction leads to a successful future.
Marketing Team
The team's key responsibility is to ensure that UNGAR broad range of and product ranges are communicated effectively both internally and externally; With a thorough understanding of product development, promotion, release strategies, training, and evaluation we ensure our products are designed to meet your needs.
Procurement
The procurement team brings a wealth of experience to an extremely important role, with the coordinate efforts the procurement team ensures UNGAR products are in-stock when you need it.
Accounts
The accounts teams are responsible for the day-to-day balances and checks of all financial transactions, giving stakeholder's confidence in their long term business relationships with UNGAR.
UNGAR's professional design team with 5 experienced designers in mechanical, pneumatical, and electrical field with more than 10years designing experiance. Headquater localed in Viena Austria.
Our Advantage and Service
Welded body with steel plate and high intensity.
Main motor is made by Siemens.
Adopts combined pneumatic friction clutch and brake.
Cluster gear adopts the flooding oil lubrication.
Six-face rectangle lengthen guide;
Equipped with hydraulic overload protecting device.
Electric shut height adjustment with digital display.
Equipped with lifting balance cylinder.
Welded body with steel plate and high intensity.
