I. Technical parameters:
1. Output paper style: Kraft paper, cardboard;
2. Raw material: Recycle paper;
3. Output paper weight: 140-260G/M2;
4. Net paper width: 1200mm;
5. Width of cylinder mould: 1450mm;
6. Capacity: 5T/D;
7 Rail gauge: 1800mm;
8 Drive way: AC inverter speed, section drive;
II. Structure of main part:
1. Cylinder section: Dia1250mm× 1450mm stainless steel cylinder mould 2 PCS, dia350mm× 1450mm couch roll 2 PCS, dia350mm× 1450mm reverse roll 1 PCS, coated by rubber, rubber hardness HSD 38C± 2, reverse roll device.
2. Press section: Dia450mm× 1450mm natural marble roll 1 PCS, dia400mm× 1450mm rubber roll 1 PCS, coated by rubber, rubber hardness HSD 90C± 2, pneumatic loading device.
3. Dryer section: Dia1500mm× 1450mm alloy dryer can 2PCS, dia450mm× 1450mm touch roll1 PCS, dia300mm× 1450mm 2ND press roll 1 PCS, coated by rubber, Rubber hardness HSD 90C± 2., pneumatic loading device, 2ND dryer can section with dry net device.
|
NO. |
Item |
qty(set) |
|
1 |
1092mm kraft paper making machine |
1 |
|
2 |
double layer exhausted hood of dryer can |
1 |
|
3 |
dia700mm axial-flow ventilator |
1 |
|
4 |
Model-13 Roots vacuum pump |
1 |
|
5 |
cylinder vat |
2 |
|
6 |
Suction box |
2 |
|
7 |
3 m3high consistency hydrapulper |
1 |
|
8 |
1.8m2 High frequency vibration screen |
1 |
|
9 |
dia380mm double disc pulp refiner |
1 |
|
12 |
6 inch pulp pump |
2 |
|
13 |
4 inch pulp pump |
4 |
|
14 |
dia700mmThruster |
2 |
|
15 |
Model-600 sand remover |
1group |
|
16 |
IS125-100sand removing pump |
1 |
|
17 |
8 m3cylinder thickener |
1 |
|
18 |
1092mm winding machine |
1 |
|
19 |
1092mm rewinding machine |
1 |
|
20 |
inverter control cabinet |
1 |
|
21 |
1ton boiler(burn coal) |
1 |
Zhengzhou guang mao machinery manufacturing Co., Ltd. is located in zhengzhou city, China. We are a leading and professional paper machine manufacturer in China.
We specialize in the manufacture of paper machines, paper processing machines and paper machine parts.
Our company has perfect service system. We have experienced engineer teams, who can supply perfect service during the whole deal, including technology consultation, civil work design, project evaluation; Installation and testing the whole production line; Training engineers and workers; Meanwhile, we also supply spare parts for long time and manufacture machines in accordance with customers' special requirements.
1. Following is main introduction of our company:
(1) total area of factory: 20, 000m2;
(2) total qty of workshop: 4;
(3) workers: 110 workers;
(4)engineer qty: 25 engineers;
2. Why you choose us?
(1) professional engineer team with 30years experience;
(2) we can supply you turn -key solution without any trouble;
(3) we have strict quality control system and ensure there is no unqualifiedly product;
(4) professional installation technician and clear technical training for your workers;
(5) strict recalling system: If any problem of machine, we will recall it and change a new one for free;
3. About shipment:
1. Sea transportation and rail way transportation is our main shipment way.
2 the delivery time is decided by your the machine model, we can also adjust delivery time according to your special requirement;
We hope to establish friendship and business relationship with friends from all over the world.
