I: Technical data:
Raw material: Recycled paper
Output paper: Kraft paper, fluting paper;
Output weight: 120-350G/M2;
Net paper width:
Capacity: 10-15ton/day;
Rail gauge: 3000mm
Drive way: AC variable frequency speed, drive part by part;
II: Main structure of the equipment:
Cylinder part: φ 1500mmX2400mm stainless steel cylinder mould 4 sets. 12mm polyethylene plastic board mesh vat 4PCS. φ 450X2400mm couch roll 5PCS, 1PCS reverse roll included.
Press part: φ 650mmX2400mm natural marble roll 1 PCS. φ 600mmX2400mm rubber roll 1 PCS, pneumatic pressurizing device, rubber hardness 38° ± 2.
Dryer part: φ 2500mmX2400mm dryer can 1 PCS, φ 1500mmX2400mm dryer can 3PCS. φ 650mmX2400mm touch roll 1PCS. Pneumatic pressurizing device, rubber hardness 90° ± 2. Dry mesh device in dryer can groups.
Model design: Cast iron stander automatic pressurizing.
Drive way: Reducer\coupling\variable frequency \adjustable speed.
|
No |
Name |
Quantity(set) |
|
1 |
2100mm four cylinder multi-wire paper machine |
1 |
|
2 |
Exhaust hood of the dryer can |
1 |
|
3 |
Axial-flow fan |
1 |
|
4 |
15type roots pump |
1 |
|
5 |
Suction box |
4 |
|
6 |
2100mm calender |
1 |
|
7 |
2100mm winding machine |
1 |
|
8 |
2100mm rewinding machine |
1 |
|
9 |
5m3 hydrapulper |
2 |
|
10 |
1.8m2 vibrating screen |
2 |
|
11 |
35m3 bleacher |
1 |
|
12 |
0.9m2 centrifugal screen |
2 |
|
13 |
φ 700mm impeller |
6 |
|
14 |
φ 380double disc refiner |
3 |
|
15 |
6inch pulp pump |
6 |
|
16 |
4inch pulp pump |
5 |
|
17 |
606desander |
10pcs (3groups) |
|
18 |
Variable frequency controller cabinet |
1 |
|
19 |
4ton boiler |
1 |
Zhengzhou guang mao machinery manufacturing Co., Ltd. is located in zhengzhou city, China. We are a leading and professional paper machine manufacturer in China.
We specialize in the manufacture of paper machines, paper processing machines and paper machine parts.
Our company has perfect service system. We have experienced engineer teams, who can supply perfect service during the whole deal, including technology consultation, civil work design, project evaluation; Installation and testing the whole production line; Training engineers and workers; Meanwhile, we also supply spare parts for long time and manufacture machines in accordance with customers' special requirements.
1. Following is main introduction of our company:
(1) total area of factory: 20, 000m2;
(2) total qty of workshop: 4;
(3) workers: 110 workers;
(4)engineer qty: 25 engineers;
2. Why you choose us?
(1) professional engineer team with 30years experience;
(2) we can supply you turn -key solution without any trouble;
(3) we have strict quality control system and ensure there is no unqualifiedly product;
(4) professional installation technician and clear technical training for your workers;
(5) strict recalling system: If any problem of machine, we will recall it and change a new one for free;
3. About shipment:
1. Sea transportation and rail way transportation is our main shipment way.
2 the delivery time is decided by your the machine model, we can also adjust delivery time according to your special requirement;
We hope to establish friendship and business relationship with friends from all over the world.
